This is a powerful ESP32 programmable keyborad , support by home assistant via ESPHome for home automation DIYer. It also can work with KinCony’s smart relay controller. let your wall switch panel can work with “1-click” , “2-click” and “hold on” actions. KC868-AK schematic download KC868-AK ESP32 I/O pin define KC868-AK ESPHome demo config for…
We have designed KC868-HA RS485 button adapter, let your old switch or traditional switch become smart, work with KC868-H32B Pro smart relay controller, use any “Latch” or “Momentary” switch panel work with your smart home automation. This time, regular switch can be used in smart home system.
Hardware diagram: How to config: a. Use USB-RS485 adapter connect to KC868-HA. b. download KC868-HA config tool and open it Chose your USB Serial port, baud is “9600”, parity: None click “OPEN” button. Target Relay Controller Addr: it’s your relay controller’s RS485 address, such as we use KC868-H32B Pro or KC868-A series board’s RS485 setting…
KC868-HA let your old switch or traditional switch become support RS485 modbus protocol for KinCony’s relay controller, work with KC868-H32B Pro smart relay controller, use any “Latch” or “Momentary” switch panel work with your smart home automation. PC software download: https://www.kincony.com/download/HA485_Ctrl_V1.0.4.0904.zip How to use KC868-HA online guide: https://www.kincony.com/how-to-use-rs485-button-adapter.html KC868-HA protocol for RS485 relay board: https://www.kincony.com/download/KC868-HA-protocol-for-RS485-relay-board_v106.pdf…
Hardware connection of KC868-AK ESP32 programmable keyboard: You can use 1-35 buttons for defined actions. You can use 1-36 terminal ports with extend momentary wall switch, extend cable MAX 1000 meter. Connect with relay controller by RS232 or RS485 cable. here is typical case KC868-AK work with KC868-H32B Pro smart relay controller and contact diagram:…
We have developed the first DIY product for smart home enthusiasts to cultivate everyone’s interest in electronic technology. “KC101” is 4 channels universal WiFi wireless smart switch with RF 433MHz module, it’s a DIY kit for DIYer. it for your smart home system to remotely and automatically turn ON/OFF home appliances and electronic devices by…
KC101 is 4 channels tuya universal WiFi wireless smart switch with RF 433MHz module, it’s a DIY kit for DIYer. it for your smart home system to remotely and automatically turn ON/OFF home appliances and electronic devices by mobile phone APP. It also can be controlled by 433MHz RF remoter. It can connect and control…
We have designed new version KC868-E16 V2 extend relay module. Now every relay have COM, NO, NC port and use by metal manual control switch buttons. Inside relay model : OMRON G2R-1-E SPDT every channel output : COM,NO,NC Coil voltage: 12V MAX current: 16A at 250VAC Operation Temperature: -40~55 ℃ Relay consumption: 0.53W/each Mechanical life:…
KC868-E16v2 relay module introduce Inside relay model : OMRON G2R-1-E SPDT every channel output : COM,NO,NC Coil voltage: 12V MAX current: 16A at 250VAC Operation Temperature: -40~55 ℃ Relay consumption: 0.53W/each Mechanical life: more than 5 million times Electrical life: (under rated control capacity) more than 100,000 times (ON-OFF frequency 20 times/minute) Maximum operating frequency:…
We have made arduino library for KC868-H32B Pro smart controller. it is open source and free for DIYer use. 1. Install ESP32 USB driver to your computer. download from: https://www.kincony.com/download/CH341SER.zip after installed USB driver, connect USB cable to your KC868-H32B Pro USB port. Then you will find COM port in windows OS “device manager” 2. Enable “ESP32…
We have designed KC868-E8T with Tuya module , 4G LTE module and ESP32, the 8 channel removable relay board. You can integrate KC868-E8T to home assistant by ESPHome use follow resource: a. 8 relay relay, 8 channel digital input for switch panel. 4 channel AC220V energy meter (BL0939 energy chip) for load’s voltage, current, power,…
We have designed KC868-E8T with Tuya module , 4G LTE module (4g energy) and ESP32, the 8 channel removable relay board. You can integrate KC868-E8T to home assistant by ESPHome use follow resource: a. 8 relay relay, 8 channel digital input for switch panel. 4 channel AC220V energy meter (BL0939 energy chip) for load’s voltage,…
