Posts: 17
Threads: 4
Joined: Nov 2024
Reputation:
0
12-17-2024, 04:23 PM
(This post was last modified: 12-17-2024, 04:58 PM by gal.)
No I dont know how to modify
I have followed your instructions from your links you have given me.
No I dont know how to modify
I have followed your instructions from your links you have given me .
Posts: 6,722
Threads: 848
Joined: Oct 2020
Reputation:
163
Posts: 17
Threads: 4
Joined: Nov 2024
Reputation:
0
(12-17-2024, 11:38 PM)admin Wrote: Do you using KC868-AIO? Yes
Posts: 6,722
Threads: 848
Joined: Oct 2020
Reputation:
163
12-19-2024, 02:10 AM
(This post was last modified: 12-19-2024, 02:12 AM by admin.)
here is feedback from KC868-AIO mqtt state:
Code: {"input1":{"value":false},"input2":{"value":false},"input3":{"value":false},"input4":{"value":false},"input5":{"value":false},"input6":{"value":false},"input7":{"value":false},"input8":{"value":false},"input9":{"value":false},"input10":{"value":false},"input11":{"value":false},"input12":{"value":false},"input13":{"value":false},"input14":{"value":false},"input15":{"value":false},"input16":{"value":false},"input17":{"value":false},"input18":{"value":false},"input19":{"value":false},"input20":{"value":false},"input21":{"value":false},"input22":{"value":false},"input23":{"value":false},"input24":{"value":false},"input25":{"value":false},"input26":{"value":false},"input27":{"value":false},"input28":{"value":false},"input29":{"value":false},"input30":{"value":false},"input31":{"value":false},"input32":{"value":false},"input33":{"value":false},"input34":{"value":false},"input35":{"value":false},"input36":{"value":false},"input37":{"value":false},"input38":{"value":false},"input39":{"value":false},"input40":{"value":false},"input41":{"value":false},"input42":{"value":false},"input43":{"value":false},"input44":{"value":false},"input45":{"value":false},"input46":{"value":false},"input47":{"value":false},"input48":{"value":false},"input49":{"value":false},"input50":{"value":false},"input51":{"value":false},"input52":{"value":false},"input53":{"value":false},"input54":{"value":false},"input55":{"value":false},"input56":{"value":false},"output1":{"value":false},"output2":{"value":false},"output3":{"value":false},"output4":{"value":false},"output5":{"value":false},"output6":{"value":false},"output7":{"value":false},"output8":{"value":false},"output9":{"value":false},"output10":{"value":false},"output11":{"value":false},"output12":{"value":false},"output13":{"value":false},"output14":{"value":false},"output15":{"value":false},"output16":{"value":false},"output17":{"value":false},"output18":{"value":false},"output19":{"value":false},"output20":{"value":false},"output21":{"value":false},"output22":{"value":false},"output23":{"value":false},"output24":{"value":false},"output25":{"value":false},"output26":{"value":false},"output27":{"value":false},"output28":{"value":false},"output29":{"value":false},"output30":{"value":false},"output31":{"value":false},"output32":{"value":false},"adc1":{"value":0},"adc2":{"value":0},"adc3":{"value":0},"adc4":{"value":0},"adc5":{"value":0},"adc6":{"value":0},"adc7":{"value":0},"adc8":{"value":0},"adc9":{"value":0},"adc10":{"value":0},"adc11":{"value":0},"adc12":{"value":0},"adc13":{"value":0},"adc14":{"value":0},"adc15":{"value":0},"adc16":{"value":0},"adc17":{"value":0},"adc18":{"value":0},"adc19":{"value":0},"dac1":{"value":0},"dac2":{"value":0},"dac3":{"value":0},"dac4":{"value":0},"dac5":{"value":0},"dac6":{"value":0},"dac7":{"value":0},"dac8":{"value":0},"dac9":{"value":0},"dac10":{"value":0},"dac11":{"value":0},"dac12":{"value":0},"dac13":{"value":0},"dac14":{"value":0},"dac15":{"value":0},"dac16":{"value":0},"sensor1":{"temperature":-100.0,"humidity":-100.0},"sensor2":{"temperature":-100.0,"humidity":-100.0}}
so you can modify the yaml by this way. here is yaml for KC868-AIO, it config for 32 channel digital output and 56 channel digital input ports. You ONLY need to replace with your own UID in "command_topic" and "state_topic" topic.
Code: # Loads default set of integrations. Do not remove.
default_config:
# Load frontend themes from the themes folder
frontend:
themes: !include_dir_merge_named themes
automation: !include automations.yaml
script: !include scripts.yaml
scene: !include scenes.yaml
mqtt:
switch:
- name: 'aio-kcs-output-1'
unique_id: aio-kcs-output-1
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output1":{"value":true}}'
payload_off: '{"output1":{"value":false}}'
value_template: '{{ value_json.output1.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-2'
unique_id: aio-kcs-output-2
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output2":{"value":true}}'
payload_off: '{"output2":{"value":false}}'
value_template: '{{ value_json.output2.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-3'
unique_id: aio-kcs-output-3
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output3":{"value":true}}'
payload_off: '{"output3":{"value":false}}'
value_template: '{{ value_json.output3.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-4'
unique_id: aio-kcs-output-4
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output4":{"value":true}}'
payload_off: '{"output4":{"value":false}}'
value_template: '{{ value_json.output4.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-5'
unique_id: aio-kcs-output-5
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output5":{"value":true}}'
payload_off: '{"output5":{"value":false}}'
value_template: '{{ value_json.output5.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-6'
unique_id: aio-kcs-output-6
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output6":{"value":true}}'
payload_off: '{"output6":{"value":false}}'
value_template: '{{ value_json.output6.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-7'
unique_id: aio-kcs-output-7
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output7":{"value":true}}'
payload_off: '{"output7":{"value":false}}'
value_template: '{{ value_json.output7.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-8'
unique_id: aio-kcs-output-8
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output8":{"value":true}}'
payload_off: '{"output8":{"value":false}}'
value_template: '{{ value_json.output8.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-9'
unique_id: aio-kcs-output-9
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output9":{"value":true}}'
payload_off: '{"output9":{"value":false}}'
value_template: '{{ value_json.output9.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-10'
unique_id: aio-kcs-output-10
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output10":{"value":true}}'
payload_off: '{"output10":{"value":false}}'
value_template: '{{ value_json.output10.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-11'
unique_id: aio-kcs-output-11
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output11":{"value":true}}'
payload_off: '{"output11":{"value":false}}'
value_template: '{{ value_json.output11.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-12'
unique_id: aio-kcs-output-12
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output12":{"value":true}}'
payload_off: '{"output12":{"value":false}}'
value_template: '{{ value_json.output12.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-13'
unique_id: aio-kcs-output-13
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output13":{"value":true}}'
payload_off: '{"output13":{"value":false}}'
value_template: '{{ value_json.output13.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-14'
unique_id: aio-kcs-output-14
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output14":{"value":true}}'
payload_off: '{"output14":{"value":false}}'
value_template: '{{ value_json.output14.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-15'
unique_id: aio-kcs-output-15
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output15":{"value":true}}'
payload_off: '{"output15":{"value":false}}'
value_template: '{{ value_json.output15.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-16'
unique_id: aio-kcs-output-16
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output16":{"value":true}}'
payload_off: '{"output16":{"value":false}}'
value_template: '{{ value_json.output16.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-17'
unique_id: aio-kcs-output-17
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output17":{"value":true}}'
payload_off: '{"output17":{"value":false}}'
value_template: '{{ value_json.output17.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-18'
unique_id: aio-kcs-output-18
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output18":{"value":true}}'
payload_off: '{"output18":{"value":false}}'
value_template: '{{ value_json.output18.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-19'
unique_id: aio-kcs-output-19
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output19":{"value":true}}'
payload_off: '{"output19":{"value":false}}'
value_template: '{{ value_json.output19.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-20'
unique_id: aio-kcs-output-20
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output20":{"value":true}}'
payload_off: '{"output20":{"value":false}}'
value_template: '{{ value_json.output20.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-21'
unique_id: aio-kcs-output-21
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output21":{"value":true}}'
payload_off: '{"output21":{"value":false}}'
value_template: '{{ value_json.output21.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-22'
unique_id: aio-kcs-output-22
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output22":{"value":true}}'
payload_off: '{"output22":{"value":false}}'
value_template: '{{ value_json.output22.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-23'
unique_id: aio-kcs-output-23
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output23":{"value":true}}'
payload_off: '{"output23":{"value":false}}'
value_template: '{{ value_json.output23.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-24'
unique_id: aio-kcs-output-24
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output24":{"value":true}}'
payload_off: '{"output24":{"value":false}}'
value_template: '{{ value_json.output24.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-25'
unique_id: aio-kcs-output-25
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output25":{"value":true}}'
payload_off: '{"output25":{"value":false}}'
value_template: '{{ value_json.output25.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-26'
unique_id: aio-kcs-output-26
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output26":{"value":true}}'
payload_off: '{"output26":{"value":false}}'
value_template: '{{ value_json.output26.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-27'
unique_id: aio-kcs-output-27
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output27":{"value":true}}'
payload_off: '{"output27":{"value":false}}'
value_template: '{{ value_json.output27.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-28'
unique_id: aio-kcs-output-28
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output28":{"value":true}}'
payload_off: '{"output28":{"value":false}}'
value_template: '{{ value_json.output28.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-29'
unique_id: aio-kcs-output-29
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output29":{"value":true}}'
payload_off: '{"output29":{"value":false}}'
value_template: '{{ value_json.output29.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-30'
unique_id: aio-kcs-output-30
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output30":{"value":true}}'
payload_off: '{"output30":{"value":false}}'
value_template: '{{ value_json.output30.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-31'
unique_id: aio-kcs-output-31
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output31":{"value":true}}'
payload_off: '{"output31":{"value":false}}'
value_template: '{{ value_json.output31.value }}'
state_on: true
state_off: false
- name: 'aio-kcs-output-32'
unique_id: aio-kcs-output-32
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
command_topic: 'KC868_AIO/08F9E08BCB74/SET'
payload_on: '{"output32":{"value":true}}'
payload_off: '{"output32":{"value":false}}'
value_template: '{{ value_json.output32.value }}'
state_on: true
state_off: false
binary_sensor:
- name: 'aio-kcs-input-1'
unique_id: aio-kcs-input-1
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input1.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-2'
unique_id: aio-kcs-input-2
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input2.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-3'
unique_id: aio-kcs-input-3
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input3.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-4'
unique_id: aio-kcs-input-4
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input4.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-5'
unique_id: aio-kcs-input-5
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input5.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-6'
unique_id: aio-kcs-input-6
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input6.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-7'
unique_id: aio-kcs-input-7
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input7.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-8'
unique_id: aio-kcs-input-8
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input8.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-9'
unique_id: aio-kcs-input-9
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input9.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-10'
unique_id: aio-kcs-input-10
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input10.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-11'
unique_id: aio-kcs-input-11
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input11.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-12'
unique_id: aio-kcs-input-12
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input12.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-13'
unique_id: aio-kcs-input-13
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input13.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-14'
unique_id: aio-kcs-input-14
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input14.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-15'
unique_id: aio-kcs-input-15
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input15.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-16'
unique_id: aio-kcs-input-16
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input16.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-17'
unique_id: aio-kcs-input-17
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input17.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-18'
unique_id: aio-kcs-input-18
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input18.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-19'
unique_id: aio-kcs-input-19
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input19.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-20'
unique_id: aio-kcs-input-20
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input20.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-21'
unique_id: aio-kcs-input-21
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input21.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-22'
unique_id: aio-kcs-input-22
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input22.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-23'
unique_id: aio-kcs-input-23
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input23.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-24'
unique_id: aio-kcs-input-24
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input24.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-25'
unique_id: aio-kcs-input-25
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input25.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-26'
unique_id: aio-kcs-input-26
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input26.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-27'
unique_id: aio-kcs-input-27
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input27.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-28'
unique_id: aio-kcs-input-28
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input28.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-29'
unique_id: aio-kcs-input-29
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input29.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-30'
unique_id: aio-kcs-input-30
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input30.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-31'
unique_id: aio-kcs-input-31
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input31.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-32'
unique_id: aio-kcs-input-32
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input32.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-33'
unique_id: aio-kcs-input-33
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input33.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-34'
unique_id: aio-kcs-input-34
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input34.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-35'
unique_id: aio-kcs-input-35
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input35.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-36'
unique_id: aio-kcs-input-36
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input36.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-37'
unique_id: aio-kcs-input-37
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input37.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-38'
unique_id: aio-kcs-input-38
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input38.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-39'
unique_id: aio-kcs-input-39
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input39.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-40'
unique_id: aio-kcs-input-40
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input40.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-41'
unique_id: aio-kcs-input-41
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input41.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-42'
unique_id: aio-kcs-input-42
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input42.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-43'
unique_id: aio-kcs-input-43
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input43.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-44'
unique_id: aio-kcs-input-44
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input44.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-45'
unique_id: aio-kcs-input-45
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input45.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-46'
unique_id: aio-kcs-input-46
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input46.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-47'
unique_id: aio-kcs-input-47
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input47.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-48'
unique_id: aio-kcs-input-48
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input48.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-49'
unique_id: aio-kcs-input-49
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input49.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-50'
unique_id: aio-kcs-input-50
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input50.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-51'
unique_id: aio-kcs-input-51
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input51.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-52'
unique_id: aio-kcs-input-52
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input52.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-53'
unique_id: aio-kcs-input-53
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input53.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-54'
unique_id: aio-kcs-input-54
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input54.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-55'
unique_id: aio-kcs-input-55
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input55.value }}'
payload_on: true
payload_off: false
- name: 'aio-kcs-input-56'
unique_id: aio-kcs-input-56
state_topic: 'KC868_AIO/08F9E08BCB74/STATE'
value_template: '{{ value_json.input56.value }}'
payload_on: true
payload_off: false
yaml file download:
AIO-mqtt-HA.txt (Size: 23.81 KB / Downloads: 8)
check your own UID of KC868-AIO at INDEX webpage.
Posts: 17
Threads: 4
Joined: Nov 2024
Reputation:
0
Hi
Thanks for your reply and support all working great now.
I have Sensors that I would like to add to the kc868 aio, eg- water temperature sensors ,temperature and humidity sensors, water level sensors and human presence sensors that I have purchased from you, how do I integrate these to the aio using kcs firmware.
Posts: 6,722
Threads: 848
Joined: Oct 2020
Reputation:
163
water temperature sensors ,temperature and humidity sensors, water level sensors need all details. such as which are analog 0-5v sensor? which is DS18B20? human presence sensor just connect to your digital input port.
Posts: 17
Threads: 4
Joined: Nov 2024
Reputation:
0
Posts: 6,722
Threads: 848
Joined: Oct 2020
Reputation:
163
when i have free time, will update the yaml for use these sensor. the last one, VALVE is not a sensor, you can connect with relay output port to drive it.
Posts: 17
Threads: 4
Joined: Nov 2024
Reputation:
0
(12-20-2024, 12:52 PM)admin Wrote: when i have free time, will update the yaml for use these sensor. the last one, VALVE is not a sensor, you can connect with relay output port to drive it.
Ok, Thank you.
I have just received my b16m and f24 today all installed all working ok .
I want to get my door access keypad put on to the B16m using wiegand , I have installed the B16m to esphome to do this as you mentioned before I cannot use this if I have Kcs firmware installed is that correct?, what 2 gpios do I use on the B16m for the 2 data wires from the access control keypad?
Thanks for your support much appreciated.
Posts: 6,722
Threads: 848
Joined: Oct 2020
Reputation:
163
KCS firmware not support wiegand directly, maybe in future will update for that.
now you can config by ESPHome, if you want to use wiegand device. any free GPIOs can be used by wiegand device.
|
