Hi to All,

Its my first post here and i so hapy that i can do all this things regarding automation by myself.  it's really satisfying.
I decided to go with Kincony.

I will use:

KC868 - Server with RP and Home assistant.
KC868- A64
KC868 - AIO

KC868 -E16 x 5

KC868- A64 it will be used to connect 64 wall swiches via LAN cable cat 6 to Digital Input,
on outpot side it will be conected to  KC868 -E16 x 4 to control all lights in home.

it will be powered by 12 v 2 A power supply. It will be enought?
what type of cable i shoud use to connect Digital Outpot to E16?
For what type of use is ITC Expand?


KC868-AIO will be used to connect 16 led strips via 0-10 V
DO  will be conected to  KC868 -E16  control roller shutter
on DI will be conected to wall swiches to control shutters also i woudl like to connect here some wall swiches that will be able to turn on led and some contactrons.

if there is any option to configure IFTTT that when i double click wall swich connected to  KC868- A64 it will turn off all DO in KC868- A64 and  some KC868-AIO
AIO has some Analog input for sensors wich one i should buy to have information about temperature , maybe humidity also ?
which type of sensor it can operate and how long cable it can have?

KC868 - Server will be used for RP and connection to electric metter via modbus RTU.
and control sprinkels garage etc via 12 v



Thanks for help.

i am using kc868-a64 board controlling for lights and  smoke detectors. i also have 1 separate esp32 dev board which is controlling my ac through IR and ld2410 sensor for presence detection.

kc868-a64 communicating through  Rj-45 and esp32 dev communicating through wifi they both working really nice under home assistant,

now i want to connect kc868-a64 and esp32 through rs-485 for sending my IR data and getting ld2410 readings from esp32 dev kit to home assistant. how to send ir data and receive sensors reading    through rs-485 from esp32 dev kit to kc868-a64

we have designed KC868-E16P ESP32 home automation extend relay module. PCB with manual control buttons. it’s based on ESP32 , Ethernet POE + RS485 + 4CH analog input + 16CH digital input and 16CH digital output by 16A OMRON relay. Support ESPHome for home assistant and Tasmota firmware and "KCS: tuya app for home automation DIY.


Hi everyone,
I ask a silly thing: what maximum voltage can the 8 inputs (clean contacts) of the KC868-A8 board have? 12v? 220v?
The doubt arises from the fact that, when powered, with the tester, I measure 12v between the common and input 1 or input 2 or input 3 etc. etc.

Thanks
Pier

Hello.
Anybody else having issues to read meter (KC868-Meter-1PV-RS485) data with KC868-COLB using Kincony Smart Board controller software?
Steps taken:
1. connected the Meter to COLB. Wire B to 12, wire A to 11
2. no other sensors or devices are connected to COLB, only the meter
3. successfully connected to COLB with Kincony SCB_V1.0.410.504
4. Enabled Autoreport
5. Opened the EMeter page
6. Set meter ID number
7. Clicked the Read button

After waiting about 1 minute all fields (kWH, V, A, kW, Q, Hz) are still 0.
Changed the meter to another one (replaced the meter ID in Kincony SCB_V1.0.410.504 ) but the result is the same. Cannot read meter data.

Any help will be appreciated. Thank you.

Can you please help me with MQTT setup for the KC868-A8S board? It's already configured but I still cannot operate from Home Assistant. I believe it UID issue.
Thank you.

ANALOG_A1  GPIO36
ANALOG_A2  GPIO35
ANALOG_A3  GPIO34
ANALOG_A4  GPIO39

IIC SDA:GPIO16
IIC SCL:GPIO15

PCF8574:U27 (relay1-8): 100 001 = 0x21
PCF8574:U28 (relay9-16): 100 101 = 0x25

PCF8574:U23 (DI1-8): 100 010 = 0x22
PCF8574:U24 (DI9-16): 100 100 = 0x24

RF433MHz wireless receiver: GPIO4

Ethernet (LAN8720) I/O define:

#define ETH_ADDR        0
#define ETH_POWER_PIN  -1
#define ETH_MDC_PIN    23
#define ETH_MDIO_PIN  18
#define ETH_TYPE      ETH_PHY_LAN8720
#define ETH_CLK_MODE  ETH_CLOCK_GPIO17_OUT

--------------------
RS485:
RXD:GPIO13
TXD:GPIO32

Extend serial port (3.3v TTL level):
RXD:GPIO14
TXD:GPIO33

IR receiver: IO23
IR sender: IO2

433MHz receiver: IO13
433MHz sender: IO22

Buzzer: IO4

Zigbee CP2652:
RXD:32
TXD:33

free GPIO:
IO26,IO14,IO34,IO21,IO18
IO25,IO27,IO39,IO35,IO19

tasmota config module GPIO for Zigbee module RXD,TXD pins:


AG Pro work with Xiaomi Zigbee temperature & humidity sensor:


tasmota zigbee firmware download:

  tasmota32_CP2652.zip (Size: 1.03 MB / Downloads: 1084)

or you can download newest firmware from tasmota official webpage:
http://ota.tasmota.com/tasmota32/release/

ESP flasher for ESP32, ESP32-C3, ESP32-S2, ESP32-S3 and ESP8266 (Tasmota) download:
https://github.com/Jason2866/ESP_Flasher/releases
