[arduino code examples for F16]-04 RS485 communication test

Posted by: admin - 10-01-2024, 04:45 AM - Forum: F16 - No Replies

Code:
/*

 * Made by KinCony IoT: https://www.kincony.com

 *

 * RS485 Communication Test

 *

 * This program is a simple test for RS485 communication using ESP32-S3.

 * It will send a message over RS485 and then read incoming messages.

 * The TXD pin is defined as GPIO 16 and RXD pin is defined as GPIO 17.

 */

#include <HardwareSerial.h>

// Define RS485 pins

#define RS485_RXD 17

#define RS485_TXD 16

// Create a hardware serial object

HardwareSerial rs485Serial(1);

void setup() {

  // Start serial communication for debugging

  Serial.begin(115200);

  while (!Serial);

  // Initialize RS485 Serial communication

  rs485Serial.begin(9600, SERIAL_8N1, RS485_RXD, RS485_TXD);

  Serial.println("RS485 Test Start");

}

void loop() {

  // Send a test message

  rs485Serial.println("Hello from KinCony F16!");

  // Wait for a short period

  delay(1000);

  // Check if data is available to read

  if (rs485Serial.available()) {

    String receivedMessage = "";

    while (rs485Serial.available()) {

      char c = rs485Serial.read();

      receivedMessage += c;

    }

    // Print the received message

    Serial.print("Received: ");

    Serial.println(receivedMessage);

  }

  // Wait before sending the next message

  delay(2000);

}

arduino ino file download:
.zip

4-RS485-Test.zip (Size: 763 bytes / Downloads: 40)
BIN file (you can use esp32 download tool download to ESP32-S3 with address 0x0 then directly to use) download:
.zip

4-RS485-Test.ino.merged.zip (Size: 182.25 KB / Downloads: 41)

[arduino code examples for F16]-03 Read analog input ports value

Posted by: admin - 10-01-2024, 04:43 AM - Forum: F16 - No Replies

Code:
/*

 * Made by KinCony IoT: https://www.kincony.com

 *

 * Description:

 * This Arduino program reads analog values from four analog input pins (A1, A2, A3, A4)

 * and prints the values to the Serial Monitor. The analog inputs are defined with specific

 * GPIO pins and the program reads the voltage levels from these pins every 2 seconds.

 *

 * Pin Definitions:

 * - A1: GPIO 5

 * - A2: GPIO 7

 * - A3: GPIO 6

 * - A4: GPIO 4

 */

#define ANALOG_A1   5   // Define GPIO pin for analog input A1

#define ANALOG_A2   7   // Define GPIO pin for analog input A2

#define ANALOG_A3   6   // Define GPIO pin for analog input A3

#define ANALOG_A4   4   // Define GPIO pin for analog input A4

void setup()

{

    Serial.begin(115200); // Initialize serial communication at 115200 baud rate

    delay(500); // Short delay to allow serial communication to start

    pinMode(ANALOG_A1, INPUT); // Set GPIO 5 as an input for analog signal A1

    pinMode(ANALOG_A2, INPUT); // Set GPIO 7 as an input for analog signal A2

    pinMode(ANALOG_A3, INPUT); // Set GPIO 6 as an input for analog signal A3

    pinMode(ANALOG_A4, INPUT); // Set GPIO 4 as an input for analog signal A4

}

void loop()

{

    // Read and print analog values from the defined pins

    Serial.print("A1=");

    Serial.println(analogRead(ANALOG_A1)); // Read and print the value from A1

    Serial.print("A2=");

    Serial.println(analogRead(ANALOG_A2)); // Read and print the value from A2

    Serial.print("A3=");

    Serial.println(analogRead(ANALOG_A3)); // Read and print the value from A3

    Serial.print("A4=");

    Serial.println(analogRead(ANALOG_A4)); // Read and print the value from A4

    delay(2000); // Wait for 2 seconds before the next reading

}

arduino ino file download:
.zip

3-analog-input.zip (Size: 769 bytes / Downloads: 40)
BIN file (you can use esp32 download tool download to ESP32-S3 with address 0x0 then directly to use) download:
.zip

3-analog-input.ino.merged.zip (Size: 182.45 KB / Downloads: 33)

[arduino code examples for F16]-02 Read digital input ports state

Posted by: admin - 10-01-2024, 04:41 AM - Forum: F16 - No Replies

Code:
/*

 * Made by KinCony IoT: https://www.kincony.com

 *

 * Description:

 * This Arduino program reads the state of a 16-channel PCF8575 I/O expander

 * and prints the state of all input pins to the Serial Monitor. The state of

 * each pin is represented as a bit in a 16-bit value, where each bit corresponds

 * to an input pin. The program prints the input state in binary format.

 *

 * Pin Definitions:

 * - SDA: GPIO 21

 * - SCL: GPIO 22

 * - PCF8575 I2C Address: 0x24

 */

#include "Arduino.h"

#include "PCF8575.h"

// Define I2C pins

#define I2C_SDA 8  // Define SDA pin

#define I2C_SCL 18  // Define SCL pin

// Set I2C address

PCF8575 pcf8575_IN1(0x24); // The I2C address of the PCF8575

void setup() {

    Serial.begin(115200);

    // Initialize I2C communication

    Wire.begin(I2C_SDA, I2C_SCL); // Initialize I2C with defined SDA and SCL pins

    pcf8575_IN1.begin(); // Initialize the PCF8575

    Serial.println("KinCony F16 16 channel input state 0:ON  1:OFF");

}

void loop() {

    uint16_t state = 0;

    // Read the state of each pin (assuming 16 pins)

    for (int pin = 0; pin < 16; pin++) {

        if (pcf8575_IN1.read(pin)) {

            state |= (1 << pin); // Set the bit for the active pin

        }

    }

    Serial.print("Input state: ");

    Serial.println(state, BIN); // Print the state of inputs in binary

    delay(500); // Delay 500ms

}

arduino ino file download:
.zip

2-digital-input.zip (Size: 839 bytes / Downloads: 35)
BIN file (you can use esp32 download tool download to ESP32-S3 with address 0x0 then directly to use) download:
.zip

2-digital-input.ino.merged.zip (Size: 187.5 KB / Downloads: 36)

[arduino code examples for F16]-01 Turn ON/OFF relay

Posted by: admin - 10-01-2024, 04:40 AM - Forum: F16 - No Replies

Code:
/*

 * Made by KinCony IoT: https://www.kincony.com

 *

 * This program controls a 16-channel relay board via a PCF8575 I/O expander.

 * It sequentially turns on each relay and then turns them off in a loop.

 *

 * Pin Definitions:

 * - SDA: GPIO 8

 * - SCL: GPIO 18

 *

 * Delay Time:

 * - 200 milliseconds between switching relays

 */

#include <Wire.h>        // Include the Wire library for I2C communication

#include <PCF8575.h>     // Include the PCF8575 library to control the I/O expander

#define SDA 8            // Define the SDA pin

#define SCL 18           // Define the SCL pin

#define DELAY_TIME 200   // Define the delay time in milliseconds

// Set I2C address of the PCF8575 module

#define I2C_ADDRESS 0x25 // I2C address of the PCF8575 module

PCF8575 pcf8575_R1(I2C_ADDRESS); // Create a PCF8575 object with the specified I2C address

void setup() {

  // Initialize I2C communication

  Wire.begin(SDA, SCL); // SDA on GPIO 8, SCL on GPIO 18 (according to your board's configuration)

  // Initialize serial communication for debugging (optional)

  Serial.begin(115200);

  Serial.println("PCF8575 Relay Control: Starting...");

  // Initialize the PCF8575 module

  pcf8575_R1.begin();

  // Turn off all relays initially (set all pins HIGH)

  for (int i = 0; i < 16; i++) {

    pcf8575_R1.write(i, HIGH); // Set all relays to OFF (assuming HIGH means OFF for relays)

  }

}

void loop() {

  // Sequentially turn on each relay

  for (int i = 0; i < 16; i++) {

    pcf8575_R1.write(i, LOW);   // Turn on the relay at pin i (LOW means ON for the relay)

    delay(DELAY_TIME);          // Wait for DELAY_TIME milliseconds

  }

  // Sequentially turn off each relay

  for (int i = 0; i < 16; i++) {

    pcf8575_R1.write(i, HIGH);  // Turn off the relay at pin i (HIGH means OFF for the relay)

    delay(DELAY_TIME);          // Wait for DELAY_TIME milliseconds

  }

}

arduino ino file download:
.zip

1-relay.zip (Size: 925 bytes / Downloads: 36)
BIN file (you can use esp32 download tool download to ESP32-S3 with address 0x0 then directly to use) download:
.zip

1-relay.ino.merged.zip (Size: 187.22 KB / Downloads: 32)

F16 ESPHome yaml for home assistant

Posted by: admin - 10-01-2024, 04:38 AM - Forum: F16 - Replies (6)

Code:
esphome:

  name: f16

  friendly_name: f16

  platformio_options:

    board_build.extra_flags:

      # WIFI_CONTROL_SELF_MODE = 0

      # WIFI_CONTROL_SELF_MODE = 1

      - "-DWIFI_CONTROL_SELF_MODE=1"

esp32:

  board: esp32-s3-devkitc-1

  framework:

    type: arduino

external_components:

  - source:

      type: git

      url: https://github.com/hzkincony/esphome-tuya-wifi-mcu

      ref: v1.1.0

# Enable logging

  # hardware_uart: USB_SERIAL_JTAG

# Enable Home Assistant API

api:

  encryption:

    key: "WeVOuL5oNhjXcfzXtTirlOwvtWvCD5yqIxd3oV4es1k="

ethernet:

  type: W5500

  clk_pin: GPIO42

  mosi_pin: GPIO43

  miso_pin: GPIO44

  cs_pin: GPIO41

  interrupt_pin: GPIO2

  reset_pin: GPIO1

i2c:

   - id: bus_a

     sda: 8

     scl: 18

     scan: true

     frequency: 400kHz

pcf8574:

  - id: 'pcf8574_hub_out_1'  # for output channel 1-16

    i2c_id: bus_a

    address: 0x25

    pcf8575: true

  - id: 'pcf8574_hub_in_1'  # for input channel 1-16

    i2c_id: bus_a

    address: 0x24

    pcf8575: true

uart:

  - id: uart_1    #RS485

    baud_rate: 9600

    debug:

      direction: BOTH

      dummy_receiver: true

      after:

        timeout: 10ms

    tx_pin: 16

    rx_pin: 17

  - id: tuya_mcu_uart

    tx_pin: GPIO39

    rx_pin: GPIO38

    baud_rate: 9600

tuya_wifi_mcu:

  # tuya mcu product id

  product_id: chmzlgjpadpqxdko

  uart_id: tuya_mcu_uart

  wifi_reset_pin: 28

  wifi_led_pin: 16

switch:

  - platform: uart

    uart_id: uart_1

    name: "RS485 Button"

    data: [0x11, 0x22, 0x33, 0x44, 0x55]

  - platform: gpio

    name: "f16-output01"

    id: "f16_output01"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 0

      mode: OUTPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-output1-tuya

    dp_id: 1

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "f16_output01"

  - platform: gpio

    name: "f16-output02"

    id: "f16_output02"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 1

      mode: OUTPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-output2-tuya

    dp_id: 2

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "f16_output02"

  - platform: gpio

    name: "f16-output03"

    id: "f16_output03"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 2

      mode: OUTPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-output3-tuya

    dp_id: 3

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "f16_output03"

  - platform: gpio

    name: "f16-output04"

    id: "f16_output04"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 3

      mode: OUTPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-output4-tuya

    dp_id: 4

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "f16_output04"

  - platform: gpio

    name: "f16-output05"

    id: "f16_output05"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 4

      mode: OUTPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-output5-tuya

    dp_id: 5

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "f16_output05"

  - platform: gpio

    name: "f16-output06"

    id: "f16_output06"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 5

      mode: OUTPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-output6-tuya

    dp_id: 6

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "f16_output06"

  - platform: gpio

    name: "f16-output07"

    id: "f16_output07"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 6

      mode: OUTPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-output7-tuya

    dp_id: 101

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "f16_output07"

  - platform: gpio

    name: "f16-output08"

    id: "f16_output08"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 7

      mode: OUTPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-output8-tuya

    dp_id: 102

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "f16_output08"

  - platform: gpio

    name: "f16-output09"

    id: "f16_output09"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 8

      mode: OUTPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-output9-tuya

    dp_id: 103

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "f16_output09"

  - platform: gpio

    name: "f16-output10"

    id: "f16_output10"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 9

      mode: OUTPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-output10-tuya

    dp_id: 104

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "f16_output10"

  - platform: gpio

    name: "f16-output11"

    id: "f16_output11"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 10

      mode: OUTPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-output11-tuya

    dp_id: 105

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "f16_output11"

  - platform: gpio

    name: "f16-output12"

    id: "f16_output12"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 11

      mode: OUTPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-output12-tuya

    dp_id: 106

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "f16_output12"

  - platform: gpio

    name: "f16-output13"

    id: "f16_output13"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 12

      mode: OUTPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-output13-tuya

    dp_id: 107

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "f16_output13"

  - platform: gpio

    name: "f16-output14"

    id: "f16_output14"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 13

      mode: OUTPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-output14-tuya

    dp_id: 108

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "f16_output14"

  - platform: gpio

    name: "f16-output15"

    id: "f16_output15"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 14

      mode: OUTPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-output15-tuya

    dp_id: 109

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "f16_output15"

  - platform: gpio

    name: "f16-output16"

    id: "f16_output16"

    pin:

      pcf8574: pcf8574_hub_out_1

      number: 15

      mode: OUTPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-output16-tuya

    dp_id: 110

    # hide from homeassistant ui

    internal: true

    # bind other switch, sync state

    bind_switch_id: "f16_output16"

binary_sensor:

  - platform: gpio

    name: "f16-input01"

    id: "f16_input01"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 0

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-input1-tuya

    dp_id: 111

    bind_binary_sensor_id: f16_input01

    internal: true

  - platform: gpio

    name: "f16-input02"

    id: "f16_input02"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 1

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-input2-tuya

    dp_id: 112

    bind_binary_sensor_id: f16_input02

    internal: true

  - platform: gpio

    name: "f16-input03"

    id: "f16_input03"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 2

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-input3-tuya

    dp_id: 113

    bind_binary_sensor_id: f16_input03

    internal: true

  - platform: gpio

    name: "f16-input04"

    id: "f16_input04"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 3

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-input4-tuya

    dp_id: 114

    bind_binary_sensor_id: f16_input04

    internal: true

  - platform: gpio

    name: "f16-input05"

    id: "f16_input05"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 4

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-input5-tuya

    dp_id: 115

    bind_binary_sensor_id: f16_input05

    internal: true

  - platform: gpio

    name: "f16-input06"

    id: "f16_input06"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 5

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-input6-tuya

    dp_id: 116

    bind_binary_sensor_id: f16_input06

    internal: true

  - platform: gpio

    name: "f16-input07"

    id: "f16_input07"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 6

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-input7-tuya

    dp_id: 117

    bind_binary_sensor_id: f16_input07

    internal: true

  - platform: gpio

    name: "f16-input08"

    id: "f16_input08"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 7

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-input8-tuya

    dp_id: 118

    bind_binary_sensor_id: f16_input08

    internal: true

  - platform: gpio

    name: "f16-input09"

    id: "f16_input09"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 8

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-input9-tuya

    dp_id: 119

    bind_binary_sensor_id: f16_input09

    internal: true

  - platform: gpio

    name: "f16-input10"

    id: "f16_input10"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 9

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-input10-tuya

    dp_id: 120

    bind_binary_sensor_id: f16_input10

    internal: true

  - platform: gpio

    name: "f16-input11"

    id: "f16_input11"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 10

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-input11-tuya

    dp_id: 121

    bind_binary_sensor_id: f16_input11

    internal: true

  - platform: gpio

    name: "f16-input12"

    id: "f16_input12"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 11

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-input12-tuya

    dp_id: 122

    bind_binary_sensor_id: f16_input12

    internal: true

  - platform: gpio

    name: "f16-input13"

    id: "f16_input13"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 12

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-input13-tuya

    dp_id: 123

    bind_binary_sensor_id: f16_input13

    internal: true

  - platform: gpio

    name: "f16-input14"

    id: "f16_input14"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 13

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-input14-tuya

    dp_id: 124

    bind_binary_sensor_id: f16_input14

    internal: true

  - platform: gpio

    name: "f16-input15"

    id: "f16_input15"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 14

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-input15-tuya

    dp_id: 125

    bind_binary_sensor_id: f16_input15

    internal: true

  - platform: gpio

    name: "f16-input16"

    id: "f16_input16"

    pin:

      pcf8574: pcf8574_hub_in_1

      number: 15

      mode: INPUT

      inverted: true

  - platform: tuya_wifi_mcu

    name: f16-input16-tuya

    dp_id: 126

    bind_binary_sensor_id: f16_input16

    internal: true

##pull-up resistance on PCB

  - platform: gpio

    name: "f16-W1-io48"

    pin:

      number: 48

      inverted: true

  - platform: gpio

    name: "f16-W1-io47"

    pin:

      number: 47

      inverted: true

  - platform: gpio

    name: "f16-W1-io21"

    pin:

      number: 21

      inverted: true

  - platform: gpio

    name: "f16-W1-io15"

    pin:

      number: 15

      inverted: true

## without resistance on PCB

  - platform: gpio

    name: "f16-W1-io13"

    pin:

      number: 13

      inverted: false

  - platform: gpio

    name: "f16-W1-io14"

    pin:

      number: 14

      inverted:  false

  - platform: gpio

    name: "f16-433M"

    pin:

      number: 40

      inverted:  false

sensor:

  - platform: adc

    pin: 5

    name: "F16 A1 Voltage"

    update_interval: 5s

    attenuation: 11db

    filters:

      - lambda:

          if (x >= 3.11) {

            return x * 1.60256;

          } else if (x <= 0.15) {

            return 0;

          } else {

            return x * 1.51;

          }

  - platform: adc

    pin: 7

    name: "F16 A2 Voltage"

    update_interval: 5s

    attenuation: 11db

    filters:

      # - multiply: 1.51515

      - lambda:

          if (x >= 3.11) {

            return x * 1.60256;

          } else if (x <= 0.15) {

            return 0;

          } else {

            return x * 1.51;

          }

  - platform: adc

    pin: 6

    name: "F16 A3 Current"

    update_interval: 5s

    unit_of_measurement: mA

    attenuation: 11db

    filters:

      - multiply: 6.66666666

  - platform: adc

    pin: 4

    name: "F16 A4 Current"

    update_interval: 5s

    unit_of_measurement: mA

    attenuation: 11db

    filters:

      - multiply: 6.66666666

web_server:

  port: 80

font:

  - file: "gfonts://Roboto"

    id: roboto

    size: 20

display:

  - platform: ssd1306_i2c

    i2c_id: bus_a

    model: "SSD1306 128x64"

    address: 0x3C

    lambda: |-

      it.printf(0, 0, id(roboto), "KinCony F16");

download yaml file:
.txt

F16-HA.txt (Size: 14.19 KB / Downloads: 111)

F16 ESP32-S3 IO pins define

Posted by: admin - 10-01-2024, 04:36 AM - Forum: F16 - No Replies

ANALOG_A1(0-5v) GPIO5
ANALOG_A2(0-5v) GPIO7
ANALOG_A3(4-20mA) GPIO6
ANALOG_A4(4-20mA) GPIO4

IIC SDA:GPIO8
IIC SCL:GPIO18

PCF8575:U27 (relay1-16) i2c address:0x25
PCF8575:U23 (DI1-16) i2c address:0x24

RF433MHz wireless receiver: GPIO40
------------------------

Ethernet (W5500) I/O define:

clk_pin: GPIO42
mosi_pin: GPIO43
miso_pin: GPIO44
cs_pin: GPIO41

interrupt_pin: GPIO2
reset_pin: GPIO1

--------------------
RS485:
RXD:GPIO17
TXD:GPIO16
--------------------
Tuya module:
RXD:GPIO38
TXD:GPIO39

Tuya network button: Tuya module's P28
Tuya network LED: Tuya module's P16

---------------------
1-wire (pull-up resistance on PCB):
1-wire1:GPIO48
1-wire2:GPIO47
1-wire3:GPIO21
1-wire4:GPIO15

1-wire (without resistance on PCB):
1-wire1:GPIO13
1-wire2:GPIO14
------------------------
SD Card:
SPI-MOSI:GPIO10
SPI-SCK:GPIO11
SPI-MISO:GPIO12
SPI-CS:GPIO9
------------------------
24C02 EPROM i2c address: 0x50
DS3231 RTC i2c address: 0x68
SSD1306 display: i2c address:0x3c

Error rs232 no funciona

Posted by: sistemasyusa - 10-01-2024, 02:16 AM - Forum: KC868-A6 - Replies (3)

	Buen día norte puedo hacer funcionar el puerto serie rs232, algún codigo de ejemplo , anexo el hardware que uso con un Arduino Attached Files Thumbnail(s)

Conectar Arduino nano y kc868

Posted by: sistemasyusa - 10-01-2024, 12:48 AM - Forum: KC868-A6 - Replies (1)

	Buen día Quiero preguntar si es posible conectar un Arduino nano directo a alguno de los pines de kc868 para comunicación serial

Kc868 Read Pwm input

Posted by: huntleight - 09-30-2024, 09:42 PM - Forum: KC868-A6 - Replies (7)

	How to read pwm input with pcf8574 ?

KC868-A16 into Home assistant via MQTT

Posted by: Ugeo - 09-30-2024, 02:25 PM - Forum: KC868-A16 - Replies (11)

	Please help us create the integration of KC868-A16 into Home assistant via MQTT. Home assistant does not see data from KC868-A16

Pages (254): « Previous 1 … 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 … 254 Next »

Login
Username:
Password:	Lost Password?
	Remember me
