Dear Sir.

I managed to use the IFTTT on the KC868-COL logical controller.
A very simple test where if the Temperature shows above 33degC Relay 1 turns on at the KC868-H32 relay board's. Both KC868-H32 relay board's and  KC868-COL logical controller are connected via a RS232 cable.

How do show the status of Relay 1 on the KC868-H32 relay board's using a LED on the NodeRed to indicate it's turned "ON"? i don't want to use a Digital in as its a waste of resource. Just a LED on NodeRED reading from the "Function" Node where when its "ON" Led lights up on the NodeRed Screen and when "OFF", LED turns off.

Regards
Subas

Attached Files

Thumbnail(s)


Do the relays support inching switching? I need the relay to turn on for 1 second and then automatically turn off.

Answer: Controller's inching switching function support by software. You can create scene mode in our "KinCony smart home" phone app. Also we have "KBOX" local network version app, that can set button for "CLICK" or "TOUCH" mode, that works without internet.

I have a h32b smart controller and yesterday i configured and connected it back up today to continue configuring it and i cann see it on the network anywhere, is there a reset button or will i have to configure it via the rs232 port.

Many thanks in advance

Gary

3 computer for install, record HDMI video, monitor the network.


All our product is open protocol and have demo source code. So you can use any program language for integration. Such as C++, Visual Basic, Java, Python, Delphi, iOS, Android ...
You can set product work as TCP Server or TCP Client mode. When Server and Client connected by TCP socket, then just send command is ok, very easy.

if you use large power current load, such as 20A, 30A, 100A...... we suggest add AC contactor or solid state relay (SSR) to extend power. You can chose 1 phase or 3 phase AC contactor for load. Controller relay output connect with AC contactor with small current.
