Hello.

I need to know how to completely reset the H23B, Seria number H32B200812520, I don´t have access to it and I can´t configure it for WEB access.
It´s very old firmware, and never been done, which if you have i want update.
I couldn´t find the manual or the PC software on the website kincony.
Thanks

Hi there
I'm trying to get the relays to work on a KC868-A6.
I'm using the KC868-A8 example source code as the basis for this and modified it as shown below:

#include “Arduino.h”
#include “PCF8574.h”

#define I2C_RELAYS_ADR 0x24
PCF8574 pcf(I2C_RELAYS_ADR);

void setup() {
Serial.begin(115200);
Serial.println(F(“Start Kincony KC868-A6 Relays example…”));
pcf.pinMode(P0, OUTPUT);
pcf.pinMode(P1, OUTPUT);
pcf.pinMode(P2, OUTPUT);
pcf.pinMode(P3, OUTPUT);
pcf.pinMode(P4, OUTPUT);
pcf.pinMode(P5, OUTPUT);
Serial.print(“Init PCF8574… “);
if (pcf.begin()){Serial.println(F(“Ok”));}
else {Serial.println(F(“Error”));}
}

void loop() {
pcf.digitalWrite(P0, HIGH);
Serial.print(F(“Relay #”)); Serial.print(P0); Serial.println(F(” ON”));
delay(10000);
pcf.digitalWrite(P0, LOW);
Serial.print(F(“Relay #”)); Serial.print(P0); Serial.println(F(” OFF”));
delay(10000);
}


Using this example, the pcf.begin statement fails and returns "Error".
Looking at the schematic diagram for the KC868-A6, the I2C SDA is set to pin 26, and the SCL is set to pin 23.  By default the PCF8574 library will default to other values, so I tried changing the statement below to the following which matches the format noted in the readme file for the PCF8574 library
 PCF8574 pcf(0x24, 26, 23);

This didn't work either and so I tried the various I2C scanners and they don't find any I2C device.

I've also ensured that the relevant pins_arduino.h file has been edited to reflect the correct SDA and SCL pin values.

One other thing I have noticed is on startup there is a strange error, see below:

ets Jun  8 2016 00:22:57
rst:0x1 (POWERON_RESET),boot:0x17 (SPI_FAST_FLASH_BOOT)
configsip: 0, SPIWP:0xee
clk_drv:0x00,q_drv:0x00,d_drv:0x00,cs0_drv:0x00,hd_drv:0x00,wp_drv:0x00
modeIO, clock div:1
load:0x3fff0030,len:1184
load:0x40078000,len:13160
load:0x40080400,len:3036
entry 0x400805e4
E (309) i2c: i2c_set_pin(873): scl an⸮4⸮⸮⸮gpio numbers are the same


The highlighted line in red looks odd but I can't find anything online to help.

Any assistance would be appreciated.

Hi

I would like to have a wall switch status monitored in Home Assistant using Node Red to do automation.  I have this configured and working as per the 4-Wall Switch Wireless remoter video.  I can see the button state change in Node Red using the debug option.

However the default behaviour without any programming is for the switch buttons to control the corresponding H16B relays, switch button 1-16 control H16B relays 1-16 directly.

After I configured Node Red in HA I can make Switch button 1 turn on H16B relay 2 but is also turns on relay 1, (by default).

Is there a way to turn off this default setting so the switch buttons don’t change the H16B relay states unless I configure it in Node Red?

Set up is
HA running Node Red
KC868-H16B V4.34  Work Mode: TCP Server for both Ethernet and Wifi
Switch Terminal Board V2.1 connect via Rs232
6 Gang Wall Self Reset Momentary Switch Toggle Button Dry Contact.  Connect via KCom and K1-K6

Any help would be appreciated.

Hey,

i am interested in a tutorial showing how to make multiple esphome kincony devices talk to each other over rs485. is this possible?

i know that you actually do it via homeassistant - but this way it is failsafe.



and the other thing what i want to do is connect a dmx interface via rs485.

https://github.com/andyboeh/esphome-dmx512

is that possible with esphome and the kincony rs485?

Are there any examples of how to use the A32 board with an I2C device?  I have 5  SHT30 I2C Temp/Humidity Sensors that I have connected to an ESP32 Dev board and working.  I've upgraded to thge A32 board as everything is integrated but I'm confused how to wire the sensors to the A32 board and read the values. I cannot find documentation that shows how to wire into the GIO pin on the A32 board.   Do you have any example code and/or wiring diagrams on how to connect  these?  Thank you in advance for any advice

Hello!

I have a TV, a stereo and a fan with different remotes.

1) How i can make KC868-AG "learn" the remotes.
2) How i integrade them with home assistant.

I saw your video with A/C and i want to do the same with the other devices

D.I.Y - Smart 3 Phase - Main Control Board for Garden / Farm Irrigation using KC868-H8B & KC868-COL-B Mini

  KINCONY Farm land Irrigation.pdf (Size: 7 MB / Downloads: 1038)

  TV Lift.pdf (Size: 3.9 MB / Downloads: 1017)
