Use case - possible?

Posted by: CG25 - 03-16-2025, 07:54 AM - Forum: KC868-A series and Uair Smart Controller - Replies (7)

	Can I use the product for this use case: - recieve RS232 signals from external source for open/close of the relay - attach OLED screen and configure display myself - read signal from distance sensor (ultrasonic analog / laser digital) - read temperature to adjust ultrasonic measurement (hot/cold air) - send measurements to server via HTTPS over LAN

multiple power distribution boxes

Posted by: daniel45 - 03-15-2025, 10:54 AM - Forum: DIY Project - Replies (1)

Hi all,

Thanks to join your forum.

I'm preparing a home installation based on HOME ASSISTANT using KC868 with rapsberry.

I need multiple power distribution boxes in different buildings based on :

One main power box ( with KC868)
3 remote connection power boxes. (with relays and analog input )

So, could you help me on which communication hardware and protocol I can use ? ( cables CAT 6 are dispached between each boxes.).

Hope my explaination are clear . Big Grin

Great thanks

Daniel

Inquiry About Sensor Compatibility with the Board

Posted by: engrezk - 03-15-2025, 07:06 AM - Forum: DIY Project - Replies (1)

The water level sensor is malfunctioning and has three terminals: two for 12 volts (one positive and one negative) and one for data. The new locally available sensor, however, has only two terminals: one for 12 volts positive and one for the data point. I will attach pictures for reference. My question is: should I connect the positive terminal to the 12-volt power source and the data terminal to the data point on the board? Is this the correct approach?

Attached Files Thumbnail(s)

Image(s)

Filename: malfunctioning.jpg Size: 106.7 KB 03-15-2025, 06:58 AM

Firmware for KC868-A16v3 Board

Posted by: classiccars - 03-14-2025, 11:57 AM - Forum: "KCS" v2 firmware system - Replies (6)

	Does anybody know wich firmware I must use for the KC868-A16v3 Board? I loaded KCS_KC868_A16_V2.2.12.zip with USB and now the board does not work anymore. Was it the wrong firmware?

KinCony B16 ESP32-S3 Smart Controller released

Posted by: admin - 03-13-2025, 01:20 PM - Forum: News - Replies (2)

KinCony B16 ESP32 smart controller based on ESP32-S3-WROOM-1U (N16R8) wifi chip. Support 16 channel relay output, 7 channel 1-wire GPIOs, 4 channel ADS1115 16bit analog input ports. One SD card using SPI bus. B16 include DS3231 high precision RTC clock chip. LCD display will show wifi and ethernet IP address and Tuya connection state. B16 have I2C bus extender and RS485 port. You can write any code by Arduino IDE / MicroPython / ESP-IDF development tool to ESP32 module. We will supply Arduino / ESP-IDF demo code for different samples. Everyone can modify and change the code for your own smart home automation system project. it support use by ESPHome for home assistant or tasmota firmware for smart home automation DIY. B16 use KCS v3 firmware, it support home assistant auto discovery function by MQTT, so without write any config code (zero code) for home assistant. KCS v3 support KinCony cloud service (official shop customer free 2 years), remote monitor and control device by webpage in anywhere. KCS v3 support KinCony board integrate to Loxone Miniserver. Support Apple HomeKit for Siri.
[Image: B16-1.jpg]
Model No. KinCony B16
Description: KinCony 16 Channel ESP32-S3 Smart Relay Controller – B16
Power supply: 12V DC
Processor: ESP32-S3-WROOM-1U (N16R8)
Size: 160mm*83mm*59mm
interfaces: Ethernet(RJ45)-LAN 100Mbps IPv4/IPv6,WiFi,RS485,Bluetooth,USB-C,LCD,I2C,Tuya Module
RTC: DS3231 high precision chip (battery socket on PCB)
SD Card: SPI bus
Installation method: DIN RAIL
LCD: SSD1306 I2C display
[Image: B16-2.jpg]
Outputs:
16CH relay Outputs, every relay use by MAX AC250V/7A
Inputs:
ADS1115 16bit ADC: 2CH analog input DC0-5V (A1,A2) 2CH analog input 4-20mA (A3,A4)
16CH dry contact inputs (optocoupler isolation, long distance circuit for MAX 500 meters cable)
3 buttons: 1:ESP32 Reset 2:ESP32 Download 3:Tuya config
1-Wire GPIO: 7CH (with pull-up resistance on PCB)
[Image: B16-3.jpg]

Relays on ESPHome not working

Posted by: CHILE19 - 03-12-2025, 10:25 PM - Forum: KC868-A16 - Replies (8)

Hey everyone!!
I just configure my brand new KC868-A16 REV 1.6 on EspHome with this code:

Code:
esphome:

  name: calefaccion-central

  friendly_name: Calefaccion Central

esp32:

  board: esp32dev

  framework:

    type: esp-idf

# Enable logging

logger:

  level: VERY_VERBOSE

# Enable Home Assistant API

api:

  encryption:

    key: "WXXXXXXXXXXXXXXXXXXXXXnEgY="

ota:

  - platform: esphome

    password: "ca97bdfXXXXXXXXXXXXXXXXdab073"

wifi:

  ssid: !secret wifi_ssid

  password: !secret wifi_password

  # Enable fallback hotspot (captive portal) in case wifi connection fails

  ap:

    ssid: "Calefaccion-Central"

    password: "69NT2lnfj2Kd"

captive_portal:

i2c:

  sda: GPIO4

  scl:

    number: GPIO5

    ignore_strapping_warning: true

pcf8574:

  - id: outputs_1_8

    address: 0x24

    pcf8575: false

switch:

  - platform: gpio

    name: "sw_caldera"

    id: sw_caldera #1

    pin:

      pcf8574: outputs_1_8

      number: 0

      mode: OUTPUT

      inverted: true

I erase all the unecesary code.

The board seams to work ok, but I cant get the realys to work.
Here is the log from ESPHome:

Code:
INFO ESPHome 2025.2.0

INFO Reading configuration /config/esphome/calefaccion-central.yaml...

INFO Starting log output from 192.168.1.133 using esphome API

INFO Successfully connected to calefaccion-central @ 192.168.1.133 in 0.221s

INFO Successful handshake with calefaccion-central @ 192.168.1.133 in 0.145s

[19:21:35][I][app:100]: ESPHome version 2025.2.0 compiled on Mar 12 2025, 19:11:06

[19:21:35][C][wifi:600]: WiFi:

[19:21:35][C][wifi:428]:   Local MAC: 20:#########:50

[19:21:35][C][wifi:433]:   SSID: [redacted]

[19:21:35][C][wifi:436]:   IP Address: 192.168.1.133

[19:21:35][C][wifi:439]:   BSSID: [redacted]

[19:21:35][C][wifi:441]:   Hostname: 'calefaccion-central'

[19:21:35][C][wifi:443]:   Signal strength: -62 dB ▂▄▆█

[19:21:35][V][wifi:445]:   Priority: 0.0

[19:21:35][C][wifi:447]:   Channel: 1

[19:21:35][C][wifi:448]:   Subnet: 255.255.255.0

[19:21:35][C][wifi:449]:   Gateway: 192.168.1.1

[19:21:35][C][wifi:450]:   DNS1: 200.28.4.130

[19:21:35][C][wifi:451]:   DNS2: 200.28.4.129

[19:21:35][C][logger:177]: Logger:

[19:21:35][C][logger:178]:   Max Level: VERY_VERBOSE

[19:21:35][C][logger:179]:   Initial Level: VERY_VERBOSE

[19:21:35][C][logger:181]:   Log Baud Rate: 115200

[19:21:35][C][logger:182]:   Hardware UART: UART0

[19:21:35][C][i2c.idf:079]: I2C Bus:

[19:21:35][C][i2c.idf:080]:   SDA Pin: GPIO4

[19:21:35][C][i2c.idf:081]:   SCL Pin: GPIO5

[19:21:35][C][i2c.idf:082]:   Frequency: 50000 Hz

[19:21:36][C][i2c.idf:088]:   Recovery: bus successfully recovered

[19:21:36][I][i2c.idf:098]: Results from i2c bus scan:

[19:21:36][I][i2c.idf:104]: Found i2c device at address 0x21

[19:21:36][I][i2c.idf:104]: Found i2c device at address 0x22

[19:21:36][I][i2c.idf:104]: Found i2c device at address 0x24

[19:21:36][I][i2c.idf:104]: Found i2c device at address 0x25

[19:21:36][C][pcf8574:021]: PCF8574:

[19:21:36][C][pcf8574:022]:   Address: 0x24

[19:21:36][C][pcf8574:023]:   Is PCF8575: NO

[19:21:36][C][switch.gpio:068]: GPIO Switch 'sw_caldera'

[19:21:36][C][switch.gpio:090]:   Restore Mode: always OFF

[19:21:36][C][switch.gpio:031]:   Pin: 0 via PCF8574

[19:21:36][C][switch.gpio:068]: GPIO Switch 'sw_bano_pieza'

[19:21:36][C][switch.gpio:090]:   Restore Mode: always OFF

[19:21:36][C][switch.gpio:031]:   Pin: 1 via PCF8574

[19:21:36][C][template.switch:068]: Template Switch 'Template Switch'

[19:21:36][C][template.switch:090]:   Restore Mode: always OFF

[19:21:36][C][template.switch:057]:   Optimistic: YES

[19:21:36][C][restart.button:017]: Restart Button 'Restart'

[19:21:36][C][restart.button:017]:   Icon: 'mdi:restart'

[19:21:36][C][captive_portal:089]: Captive Portal:

[19:21:36][C][mdns:116]: mDNS:

[19:21:36][C][mdns:117]:   Hostname: calefaccion-central

[19:21:36][V][mdns:118]:   Services:

[19:21:36][V][mdns:120]:   - _esphomelib, _tcp, 6053

[19:21:36][V][mdns:122]:     TXT: friendly_name = Calefaccion Central

[19:21:36][V][mdns:122]:     TXT: version = 2025.2.0

[19:21:36][V][mdns:122]:     TXT: mac = 20####50

[19:21:36][V][mdns:122]:     TXT: platform = ESP32

[19:21:36][V][mdns:122]:     TXT: board = esp32dev

[19:21:36][V][mdns:122]:     TXT: network = wifi

[19:21:36][V][mdns:122]:     TXT: api_encryption = Noise_NNpsk0_25519_ChaChaPoly_SHA256

[19:21:36][C][esphome.ota:073]: Over-The-Air updates:

[19:21:36][C][esphome.ota:074]:   Address: calefaccion-central.local:3232

[19:21:36][C][esphome.ota:075]:   Version: 2

[19:21:36][C][esphome.ota:078]:   Password configured

[19:21:36][C][safe_mode:018]: Safe Mode:

[19:21:36][C][safe_mode:019]:   Boot considered successful after 60 seconds

[19:21:36][C][safe_mode:021]:   Invoke after 10 boot attempts

[19:21:36][C][safe_mode:022]:   Remain in safe mode for 300 seconds

[19:21:36][C][api:140]: API Server:

[19:21:36][C][api:141]:   Address: calefaccion-central.local:6053

[19:21:36][C][api:143]:   Using noise encryption: YES

[19:21:42][VV][api.service:785]: on_switch_command_request: SwitchCommandRequest {

  key: 4158039208

  state: YES

}

[19:21:42][D][switch:012]: 'sw_caldera' Turning ON.

[19:21:42][VV][i2c.idf:201]: 0x24 TX FE

[19:21:42][D][switch:055]: 'sw_caldera': Sending state ON

[19:21:42][VV][api.service:156]: send_switch_state_response: SwitchStateResponse {

  key: 4158039208

  state: YES

}

[19:21:50][VV][api.service:785]: on_switch_command_request: SwitchCommandRequest {

  key: 4158039208

  state: NO

}

[19:21:50][D][switch:016]: 'sw_caldera' Turning OFF.

[19:21:50][VV][i2c.idf:201]: 0x24 TX FF

[19:21:50][D][switch:055]: 'sw_caldera': Sending state OFF

[19:21:50][VV][api.service:156]: send_switch_state_response: SwitchStateResponse {

  key: 4158039208

  state: NO

}

any help will be trully appriciate!!

kincony relay 4ch

Posted by: alexgr2006 - 03-12-2025, 03:05 PM - Forum: KC868-HxB series Smart Controller - Replies (1)

	hello I use app smart home but to day I can't login... I try and I see msg login failed...any link to download the app again? or other solution?

KC868-AG board type

Posted by: powerup - 03-12-2025, 01:33 AM - Forum: KC868-AG / AG Pro / AG8 / Z1 - Replies (3)

	Hi, i am programming myself the KC868-AG, i bought 2 units. 1 of them died after 1-2hrs, the other unit is working fine. The first one is giving USB device not recognized. Same cable is working fine for the other device. Q1: what chip do I choose for this device. Q2: what is the memory limit of this device, does it have enough space for OTA updates and save many RF signals? Thank you.

A32 pro lost control

Posted by: Saif Kitany - 03-11-2025, 10:19 PM - Forum: B16M - Replies (3)

	I have an issue with my A32 pro : - when I configure the Esphome yaml file and start controlling the A32 pro by homeassistant, i loose kcs firmeware ( ican’t login kcs web page). And when i reinstall kcs firmeware, then i loose the control by homeassistant!! Why is it happening?

KC 868-A32

Posted by: simona - 03-11-2025, 03:14 PM - Forum: KC868-A32/A32 Pro - Replies (3)

	Hi please does kc 868-A32 allow for modbus slave configuration . If no i have ordered 7 of them and can a request to redesign the hardware to allow for modbus slave.Thank you
