Question how to connect inductive proximity switch to KC868-A4

Posted by: homebrew - 01-16-2025, 10:02 AM - Forum: KC868-A4 - Replies (1)

	Hello, can somebody tell me, how I can connect a inductive proximity switch like the LJ12A3-4-Z BX ( LJ12A3-4-Z BX ) to the A4 Board? Thanks Werner

AG8 KCS firmware Wifi problem

Posted by: acztassi - 01-15-2025, 07:05 PM - Forum: KC868-AG / AG Pro / AG8 / Z1 - Replies (1)

	hello, I had uploaded in my AG8 the firmware "KCS_KC868_AG_V2.2.8". But it appears to do not work. The ethernet does not start, the Wifi also don't start. How to is the right way to this board?

KC868-A6 tasmota digital/analog input integration to Loxone

Posted by: sigituning - 01-15-2025, 02:10 PM - Forum: KinCony integrate with Loxone home automation - Replies (3)

	Hello, can you provide info how to integrate http commands for loxone to read digital and analog inputs via tasmota firmware? Or how we can read DI/AI inputs from this board in the loxone? Can we use e.g. UDP commands somehow in the tasmota and loxone? Thanks

KC868-A6 with waveshare LAN8720

Posted by: llast - 01-15-2025, 10:17 AM - Forum: KC868-A6 - Replies (3)

Hello,

I am trying to setup KC868-A6 with LAN using waveshare lan8720 controller - I used the following configuration:

```ethernet:
type: LAN8720
mdc_pin: GPIO23
mdio_pin: GPIO18
phy_addr: 0
```
but I keep on getting the folowing error on esphome:
[11:11:41][C][ethernet:041]: Setting up Ethernet...
[11:11:41][V][esp-idf:000]: E (1589) esp.emac: emac_esp32_init(371): reset timeout
[11:11:41]
[11:11:41][V][esp-idf:000]: E (1589) esp_eth: esp_eth_driver_install(228): init mac failed

would you be able to support this configuration?

Connect LD2420 Presence detection sensor to A8 controller.

Posted by: vijjav - 01-15-2025, 07:03 AM - Forum: KC868-A8 - Replies (5)

	Hi, I want to connect my LD2420 presence detection sensor to A8 board. Please share me the pinout details. LD2420 has RX, OT1, GND and 3v Pins LD2420 24Ghz mmWave Radar Sensor — ESPHome

[arduino code examples for A16v3]-12 digital INPUT trigger OUTPUT directly

Posted by: admin - 01-15-2025, 06:14 AM - Forum: KC868-A16v3 - No Replies

Code:
#include <Wire.h>        // I2C communication

#include <PCF8574.h>     // Library to control the PCF8575 I/O expander

// Define I2C pins

#define SDA 9           // SDA pin

#define SCL 10           // SCL pin

TwoWire I2Cone = TwoWire(0);

PCF8574 pcf8574_I1(&I2Cone, 0x21, SDA, SCL);

PCF8574 pcf8574_I2(&I2Cone, 0x22, SDA, SCL);

PCF8574 pcf8574_R1(&I2Cone, 0x24, SDA, SCL);

PCF8574 pcf8574_R2(&I2Cone, 0x25, SDA, SCL);

void setup() {

  // Initialize serial communication

  Serial.begin(115200);

  // Initialize input and relay modules

  // Set pinMode to OUTPUT

 pcf8574_R1.pinMode(P0, OUTPUT);

 pcf8574_R1.pinMode(P1, OUTPUT);

 pcf8574_R1.pinMode(P2, OUTPUT);

 pcf8574_R1.pinMode(P3, OUTPUT);

 pcf8574_R1.pinMode(P4, OUTPUT);

 pcf8574_R1.pinMode(P5, OUTPUT);

 pcf8574_R1.pinMode(P6, OUTPUT);

 pcf8574_R1.pinMode(P7, OUTPUT);

 pcf8574_R2.pinMode(P0, OUTPUT);

 pcf8574_R2.pinMode(P1, OUTPUT);

 pcf8574_R2.pinMode(P2, OUTPUT);

 pcf8574_R2.pinMode(P3, OUTPUT);

 pcf8574_R2.pinMode(P4, OUTPUT);

 pcf8574_R2.pinMode(P5, OUTPUT);

 pcf8574_R2.pinMode(P6, OUTPUT);

 pcf8574_R2.pinMode(P7, OUTPUT);

 pcf8574_I1.pinMode(P0, INPUT);

 pcf8574_I1.pinMode(P1, INPUT);

 pcf8574_I1.pinMode(P2, INPUT);

 pcf8574_I1.pinMode(P3, INPUT);

 pcf8574_I1.pinMode(P4, INPUT);

 pcf8574_I1.pinMode(P5, INPUT);

 pcf8574_I1.pinMode(P6, INPUT);

 pcf8574_I1.pinMode(P7, INPUT);

 pcf8574_I2.pinMode(P0, INPUT);

 pcf8574_I2.pinMode(P1, INPUT);

 pcf8574_I2.pinMode(P2, INPUT);

 pcf8574_I2.pinMode(P3, INPUT);

 pcf8574_I2.pinMode(P4, INPUT);

 pcf8574_I2.pinMode(P5, INPUT);

 pcf8574_I2.pinMode(P6, INPUT);

 pcf8574_I2.pinMode(P7, INPUT);

  Serial.print("Init pcf8574_R1...");

  if (pcf8574_R1.begin()){

    Serial.println("PCF8574_R1_OK");

  }else{

    Serial.println("PCF8574_R1_KO");

  }

  Serial.print("Init pcf8574_R2...");

  if (pcf8574_R2.begin()){

    Serial.println("PCF8574_R2_OK");

  }else{

    Serial.println("PCF8574_R2_KO");

  }

  Serial.print("Init pcf8574...");

  if (pcf8574_I1.begin()){

    Serial.println("pcf8574_I1_OK");

  }else{

    Serial.println("pcf8574_I1_KO");

  }

  Serial.print("Init pcf8574...");

  if (pcf8574_I2.begin()){

    Serial.println("pcf8574_I2_OK");

  }else{

    Serial.println("pcf8574_I2_KO");

  }

  pcf8574_R1.digitalWrite(P0, HIGH);

  pcf8574_R1.digitalWrite(P1, HIGH);

  pcf8574_R1.digitalWrite(P2, HIGH);

  pcf8574_R1.digitalWrite(P3, HIGH);

  pcf8574_R1.digitalWrite(P4, HIGH);

  pcf8574_R1.digitalWrite(P5, HIGH);

  pcf8574_R1.digitalWrite(P6, HIGH);

  pcf8574_R1.digitalWrite(P7, HIGH);

  pcf8574_R2.digitalWrite(P0, HIGH);

  pcf8574_R2.digitalWrite(P1, HIGH);

  pcf8574_R2.digitalWrite(P2, HIGH);

  pcf8574_R2.digitalWrite(P3, HIGH);

  pcf8574_R2.digitalWrite(P4, HIGH);

  pcf8574_R2.digitalWrite(P5, HIGH);

  pcf8574_R2.digitalWrite(P6, HIGH);

  pcf8574_R2.digitalWrite(P7, HIGH);

}

void loop() {

 uint8_t val1 = pcf8574_I1.digitalRead(P0);

 uint8_t val2 = pcf8574_I1.digitalRead(P1);

 uint8_t val3 = pcf8574_I1.digitalRead(P2);

 uint8_t val4 = pcf8574_I1.digitalRead(P3);

 uint8_t val5 = pcf8574_I1.digitalRead(P4);

 uint8_t val6 = pcf8574_I1.digitalRead(P5);

 uint8_t val7 = pcf8574_I1.digitalRead(P6);

 uint8_t val8 = pcf8574_I1.digitalRead(P7);

 uint8_t val9 = pcf8574_I2.digitalRead(P0);

 uint8_t val10 = pcf8574_I2.digitalRead(P1);

 uint8_t val11 = pcf8574_I2.digitalRead(P2);

 uint8_t val12 = pcf8574_I2.digitalRead(P3);

 uint8_t val13 = pcf8574_I2.digitalRead(P4);

 uint8_t val14 = pcf8574_I2.digitalRead(P5);

 uint8_t val15 = pcf8574_I2.digitalRead(P6);

 uint8_t val16 = pcf8574_I2.digitalRead(P7);

//------------------------------------

 if (val1==LOW) pcf8574_R1.digitalWrite(P0, LOW); else pcf8574_R1.digitalWrite(P0, HIGH);

 if (val2==LOW) pcf8574_R1.digitalWrite(P1, LOW); else pcf8574_R1.digitalWrite(P1, HIGH);

 if (val3==LOW) pcf8574_R1.digitalWrite(P2, LOW); else pcf8574_R1.digitalWrite(P2, HIGH);

 if (val4==LOW) pcf8574_R1.digitalWrite(P3, LOW); else pcf8574_R1.digitalWrite(P3, HIGH);

 if (val5==LOW) pcf8574_R1.digitalWrite(P4, LOW); else pcf8574_R1.digitalWrite(P4, HIGH);

 if (val6==LOW) pcf8574_R1.digitalWrite(P5, LOW); else pcf8574_R1.digitalWrite(P5, HIGH);

 if (val7==LOW) pcf8574_R1.digitalWrite(P6, LOW); else pcf8574_R1.digitalWrite(P6, HIGH);

 if (val8==LOW) pcf8574_R1.digitalWrite(P7, LOW); else pcf8574_R1.digitalWrite(P7, HIGH);

 if (val9==LOW) pcf8574_R2.digitalWrite(P0, LOW); else pcf8574_R2.digitalWrite(P0, HIGH);

 if (val10==LOW) pcf8574_R2.digitalWrite(P1, LOW); else pcf8574_R2.digitalWrite(P1, HIGH);

 if (val11==LOW) pcf8574_R2.digitalWrite(P2, LOW); else pcf8574_R2.digitalWrite(P2, HIGH);

 if (val12==LOW) pcf8574_R2.digitalWrite(P3, LOW); else pcf8574_R2.digitalWrite(P3, HIGH);

 if (val13==LOW) pcf8574_R2.digitalWrite(P4, LOW); else pcf8574_R2.digitalWrite(P4, HIGH);

 if (val14==LOW) pcf8574_R2.digitalWrite(P5, LOW); else pcf8574_R2.digitalWrite(P5, HIGH);

 if (val15==LOW) pcf8574_R2.digitalWrite(P6, LOW); else pcf8574_R2.digitalWrite(P6, HIGH);

 if (val16==LOW) pcf8574_R2.digitalWrite(P7, LOW); else pcf8574_R2.digitalWrite(P7, HIGH);

  // Delay for 500 milliseconds

  delay(50);

}

arduino ino file download:
.zip

12-input-trigger-output.zip (Size: 1 KB / Downloads: 867)
BIN file (you can use esp32 download tool download to ESP32-S3 with address 0x0 then directly to use) download:
.zip

12-input-trigger-output.ino.merged.zip (Size: 191.78 KB / Downloads: 801)

[arduino code examples for A16v3]-11 Print TEXT on SSD1306 OLED displayer

Posted by: admin - 01-15-2025, 06:12 AM - Forum: KC868-A16v3 - No Replies

Code:
/*

 * Made by KinCony IoT: https://www.kincony.com

 *

 * This Arduino program demonstrates how to display text on an SSD1306 128x64 OLED display using the U8g2 library.

 * The program draws two lines of text on the display:

 * - The first line is "KINCONY" in a larger font.

 * - The second line is "www.kincony.com" in a smaller font.

 *

 * The display is connected via I2C (software implementation) with:

 * - SCL (clock) on pin IO10

 * - SDA (data) on pin IO9

 *

 * The display's I2C address is set to 0x3C.

 */

#include <U8g2lib.h>  // Include the U8g2 library for controlling the OLED display

#include <Wire.h>     // Include the Wire library for I2C communication

// Initialize the display using the software I2C method (SCL = IO10, SDA = IO9)

U8G2_SSD1306_128X64_NONAME_F_SW_I2C u8g2(U8G2_R0,  10, 9, U8X8_PIN_NONE);  // Screen rotation: U8G2_R0

// Function to display page 1 content

void page1() {

  // Set font size 18 for the larger "KINCONY" text

  u8g2.setFont(u8g2_font_timR18_tf);  // Use the Times Roman font, size 18

  u8g2.setFontPosTop();               // Set the text position at the top of the display

  u8g2.setCursor(5, 0);               // Position the cursor at coordinates (5, 0)

  u8g2.print("KINCONY");              // Display the text "KINCONY" on the screen

  // Set font size 12 for the smaller "www.kincony.com" text

  u8g2.setFont(u8g2_font_timR12_tf);  // Use the Times Roman font, size 12

  u8g2.setCursor(0, 40);              // Position the cursor at coordinates (0, 40)

  u8g2.print("www.kincony.com");      // Display the text "www.kincony.com"

}

// Setup function, runs once when the program starts

void setup() {

  // Set the I2C address for the display to 0x3C

  u8g2.setI2CAddress(0x3C*2);  // I2C address shift for 8-bit format

  // Initialize the display

  u8g2.begin();

  // Enable UTF-8 character printing for the display

  u8g2.enableUTF8Print();  // Allow UTF-8 encoded text to be printed

}

// Main loop function, continuously runs after setup()

void loop() {

  // Begin the display drawing process

  u8g2.firstPage();  // Prepare the first page for drawing

  do {

    // Call the page1() function to draw content on the display

    page1();

  } while (u8g2.nextPage());  // Continue to the next page until all pages are drawn

}

arduino ino file download:
.zip

11-oled-ssd1306.zip (Size: 1.11 KB / Downloads: 870)
BIN file (you can use esp32 download tool download to ESP32-S3 with address 0x0 then directly to use) download:
.zip

11-oled-ssd1306.ino.merged.zip (Size: 201.23 KB / Downloads: 833)

[arduino code examples for A16v3]-10 RF433MHz sender

Posted by: admin - 01-15-2025, 06:10 AM - Forum: KC868-A16v3 - No Replies

Code:
/*

  Example for different sending methods

  https://github.com/sui77/rc-switch/

*/

#include <RCSwitch.h>

RCSwitch mySwitch = RCSwitch();

void setup() {

  Serial.begin(9600);

  // Transmitter is connected to Arduino Pin #10

  mySwitch.enableTransmit(18);

  // Optional set protocol (default is 1, will work for most outlets)

  // mySwitch.setProtocol(2);

  // Optional set pulse length.

  // mySwitch.setPulseLength(320);

  // Optional set number of transmission repetitions.

  // mySwitch.setRepeatTransmit(15);

}

void loop() {

  /* See Example: TypeA_WithDIPSwitches */

  mySwitch.switchOn("11111", "00010");

  delay(1000);

  mySwitch.switchOff("11111", "00010");

  delay(1000);

  /* Same switch as above, but using decimal code */

  mySwitch.send(5393, 24);

  delay(1000);

  mySwitch.send(5396, 24);

  delay(1000);

  /* Same switch as above, but using binary code */

  mySwitch.send("000000000001010100010001");

  delay(1000);

  mySwitch.send("000000000001010100010100");

  delay(1000);

  /* Same switch as above, but tri-state code */

  mySwitch.sendTriState("00000FFF0F0F");

  delay(1000);

  mySwitch.sendTriState("00000FFF0FF0");

  delay(1000);

  //delay(20000);

}

arduino ino file download:
.zip

10-RF433M-sender.zip (Size: 664 bytes / Downloads: 868)
BIN file (you can use esp32 download tool download to ESP32-S3 with address 0x0 then directly to use) download:
.zip

10-RF433M-sender.ino.merged.zip (Size: 181.71 KB / Downloads: 855)

[arduino code examples for A16v3]-09 RF433MHz decode

Posted by: admin - 01-15-2025, 06:08 AM - Forum: KC868-A16v3 - No Replies

Code:
/*

  Simple example for receiving

  https://github.com/sui77/rc-switch/

*/

#include <RCSwitch.h>

RCSwitch mySwitch = RCSwitch();

void setup() {

  Serial.begin(9600);

  mySwitch.enableReceive(digitalPinToInterrupt(8));

}

void loop() {

  if (mySwitch.available()) {

    Serial.print("Received ");

    Serial.print( mySwitch.getReceivedValue() );

    Serial.print(" / ");

    Serial.print( mySwitch.getReceivedBitlength() );

    Serial.print("bit ");

    Serial.print("Protocol: ");

    Serial.println( mySwitch.getReceivedProtocol() );

    mySwitch.resetAvailable();

  }

}

arduino ino file download:
.zip

9-RF433M-decode.zip (Size: 451 bytes / Downloads: 802)
BIN file (you can use esp32 download tool download to ESP32-S3 with address 0x0 then directly to use) download:
.zip

9-RF433M-decode.ino.merged.zip (Size: 181.08 KB / Downloads: 836)

[arduino code examples for A16v3]-08 Ethernet W5500 chip work with TCP Server mode

Posted by: admin - 01-15-2025, 06:06 AM - Forum: KC868-A16v3 - Replies (2)

Code:
/*

 * Made by KinCony IoT: https://www.kincony.com

 *

 * This Arduino program sets up an ESP32-S3 with a W5500 Ethernet module

 * as a TCP server. It listens on port 4196 and echoes back any string

 * received from a client.

 *

 * Hardware connections:

 * - CLK: GPIO42

 * - MOSI: GPIO43

 * - MISO: GPIO44

 * - CS: GPIO41

 * - RST: GPIO1

 * - INT: GPIO2

 *

 * Static IP address: 192.168.3.55

 * Subnet Mask: 255.255.255.0

 * Gateway: 192.168.3.1

 * DNS: 192.168.3.1

 */

#include <SPI.h>

#include <Ethernet.h>

// Define the W5500 Ethernet module pins

#define W5500_CS_PIN  15

#define W5500_RST_PIN 1

#define W5500_INT_PIN 2

#define W5500_CLK_PIN 42

#define W5500_MOSI_PIN 43

#define W5500_MISO_PIN 44

// MAC address for your Ethernet shield (must be unique on your network)

byte mac[] = { 0xDE, 0xAD, 0xBE, 0xEF, 0xFE, 0xED };

// Static IP address configuration

IPAddress ip(192, 168, 3, 55);       // Static IP address

IPAddress subnet(255, 255, 255, 0);   // Subnet mask

IPAddress gateway(192, 168, 3, 1);    // Default gateway

IPAddress dns(192, 168, 3, 1);        // DNS server address

// Create an EthernetServer object to handle TCP connections

EthernetServer server(4196);

void setup() {

  // Initialize serial communication

  Serial.begin(115200);

  while (!Serial) {

    ; // Wait for serial port to connect

  }

  // Initialize the W5500 module

  pinMode(W5500_RST_PIN, OUTPUT);

  pinMode(W5500_INT_PIN, INPUT);

  digitalWrite(W5500_RST_PIN, LOW);  // Reset the W5500 module

  delay(100);                       // Wait for reset to complete

  digitalWrite(W5500_RST_PIN, HIGH); // Release reset

  // Initialize SPI with the correct pin definitions

  SPI.begin(W5500_CLK_PIN, W5500_MISO_PIN, W5500_MOSI_PIN);

  // Set up the Ethernet library with W5500-specific pins

  Ethernet.init(W5500_CS_PIN);

  // Start the Ethernet connection with static IP configuration

  Ethernet.begin(mac, ip, dns, gateway, subnet);

  // Print the IP address to the serial monitor

  Serial.print("IP Address: ");

  Serial.println(Ethernet.localIP());

  // Start listening for incoming TCP connections

  server.begin();

}

void loop() {

  // Check for incoming client connections

  EthernetClient client = server.available();

  if (client) {

    Serial.println("New client connected");

    // Read data from the client and echo it back

    while (client.connected()) {

      if (client.available()) {

        char c = client.read();

        server.write(c);

      }

    }

    // Close the connection when done

    client.stop();

    Serial.println("Client disconnected");

  }

}

arduino ino file download:
.zip

8-Ethernet-W5500.zip (Size: 1.23 KB / Downloads: 902)
BIN file (you can use esp32 download tool download to ESP32-S3 with address 0x0 then directly to use) download:
.zip

8-Ethernet-W5500.ino.merged.zip (Size: 188.94 KB / Downloads: 865)

Pages (429): « Previous 1 … 154 155 156 157 158 159 160 161 162 163 164 165 166 167 168 169 170 171 172 173 174 … 429 Next »

Login
Username:
Password:	Lost Password?
	Remember me
