[Arduino IDE demo source code for KC868-A64]--#04-PCF8575_Output_code

Posted by: KinCony Support - 05-12-2022, 07:35 AM - Forum: KC868-A64 - No Replies

[Arduino IDE demo source code for KC868-A64]--#04-PCF8575_Output_code

Code:
/*www.kincony.com */

/*KC868-A64 Code of PCF8575 output*/

#include "Arduino.h"

#include "PCF8575.h"

// Set i2c address

PCF8575 pcf8575_R1(0x24,5,16);  //SDA IO5  , SCL IO16

PCF8575 pcf8575_R2(0x25,5,16);

PCF8575 pcf8575_R3(0x21,5,16);

PCF8575 pcf8575_R4(0x22,5,16);

unsigned long timeElapsed;

void setup()

{

  Serial.begin(115200);

for(int i=0;i<16;i++)

{

  pcf8575_R1.pinMode(i,OUTPUT);

  pcf8575_R2.pinMode(i,OUTPUT);

  pcf8575_R3.pinMode(i,OUTPUT);

  pcf8575_R4.pinMode(i,OUTPUT);

}

  pcf8575_R1.begin();

  pcf8575_R2.begin();

  pcf8575_R3.begin();

  pcf8575_R4.begin();

/*

pcf8575_R1.pinMode(P0,OUTPUT);

pcf8575_R1.pinMode(P1,OUTPUT);

pcf8575_R1.pinMode(P2,OUTPUT);

pcf8575_R1.pinMode(P3,OUTPUT);

pcf8575_R1.pinMode(P4,OUTPUT);

pcf8575_R1.pinMode(P5,OUTPUT);

pcf8575_R1.pinMode(P6,OUTPUT);

pcf8575_R1.pinMode(P7,OUTPUT);

pcf8575_R1.pinMode(P8,OUTPUT);

pcf8575_R1.pinMode(P9,OUTPUT);

pcf8575_R1.pinMode(P10,OUTPUT);

pcf8575_R1.pinMode(P11,OUTPUT);

pcf8575_R1.pinMode(P12,OUTPUT);

pcf8575_R1.pinMode(P13,OUTPUT);

pcf8575_R1.pinMode(P14,OUTPUT);

pcf8575_R1.pinMode(P15,OUTPUT);

pcf8575_R2.pinMode(P0,OUTPUT);

pcf8575_R2.pinMode(P1,OUTPUT);

pcf8575_R2.pinMode(P2,OUTPUT);

pcf8575_R2.pinMode(P3,OUTPUT);

pcf8575_R2.pinMode(P4,OUTPUT);

pcf8575_R2.pinMode(P5,OUTPUT);

pcf8575_R2.pinMode(P6,OUTPUT);

pcf8575_R2.pinMode(P7,OUTPUT);

pcf8575_R2.pinMode(P8,OUTPUT);

pcf8575_R2.pinMode(P9,OUTPUT);

pcf8575_R2.pinMode(P10,OUTPUT);

pcf8575_R2.pinMode(P11,OUTPUT);

pcf8575_R2.pinMode(P12,OUTPUT);

pcf8575_R2.pinMode(P13,OUTPUT);

pcf8575_R2.pinMode(P14,OUTPUT);

pcf8575_R2.pinMode(P15,OUTPUT);

pcf8575_R3.pinMode(P0,OUTPUT);

pcf8575_R3.pinMode(P1,OUTPUT);

pcf8575_R3.pinMode(P2,OUTPUT);

pcf8575_R3.pinMode(P3,OUTPUT);

pcf8575_R3.pinMode(P4,OUTPUT);

pcf8575_R3.pinMode(P5,OUTPUT);

pcf8575_R3.pinMode(P6,OUTPUT);

pcf8575_R3.pinMode(P7,OUTPUT);

pcf8575_R3.pinMode(P8,OUTPUT);

pcf8575_R3.pinMode(P9,OUTPUT);

pcf8575_R3.pinMode(P10,OUTPUT);

pcf8575_R3.pinMode(P11,OUTPUT);

pcf8575_R3.pinMode(P12,OUTPUT);

pcf8575_R3.pinMode(P13,OUTPUT);

pcf8575_R3.pinMode(P14,OUTPUT);

pcf8575_R3.pinMode(P15,OUTPUT);

pcf8575_R4.pinMode(P0,OUTPUT);

pcf8575_R4.pinMode(P1,OUTPUT);

pcf8575_R4.pinMode(P2,OUTPUT);

pcf8575_R4.pinMode(P3,OUTPUT);

pcf8575_R4.pinMode(P4,OUTPUT);

pcf8575_R4.pinMode(P5,OUTPUT);

pcf8575_R4.pinMode(P6,OUTPUT);

pcf8575_R4.pinMode(P7,OUTPUT);

pcf8575_R4.pinMode(P8,OUTPUT);

pcf8575_R4.pinMode(P9,OUTPUT);

pcf8575_R4.pinMode(P10,OUTPUT);

pcf8575_R4.pinMode(P11,OUTPUT);

pcf8575_R4.pinMode(P12,OUTPUT);

pcf8575_R4.pinMode(P13,OUTPUT);

pcf8575_R4.pinMode(P14,OUTPUT);

pcf8575_R4.pinMode(P15,OUTPUT);   */

}

void loop()

{

for(int j=0;j<16;j++)

{

  pcf8575_R1.digitalWrite(j,LOW); delay(50);

}

for(int j=0;j<16;j++)

{

  pcf8575_R2.digitalWrite(j,LOW); delay(50);

}

for(int j=0;j<16;j++)

{

  pcf8575_R3.digitalWrite(j,LOW); delay(50);

}

for(int j=0;j<16;j++)

{

  pcf8575_R4.digitalWrite(j,LOW); delay(50);

}

for(int j=0;j<16;j++)

{

  pcf8575_R1.digitalWrite(j,HIGH); delay(50);

}

for(int j=0;j<16;j++)

{

  pcf8575_R2.digitalWrite(j,HIGH); delay(50);

}

for(int j=0;j<16;j++)

{

  pcf8575_R3.digitalWrite(j,HIGH); delay(50);

}

for(int j=0;j<16;j++)

{

  pcf8575_R4.digitalWrite(j,HIGH); delay(50);

}

/*

 //R1 LOW----------------------

pcf8575_R1.digitalWrite(P0,LOW);

delay(50);

pcf8575_R1.digitalWrite(P1,LOW);

delay(50);

pcf8575_R1.digitalWrite(P2,LOW);

delay(50);

pcf8575_R1.digitalWrite(P3,LOW);

delay(50);

pcf8575_R1.digitalWrite(P4,LOW);

delay(50);

pcf8575_R1.digitalWrite(P5,LOW);

delay(50);

pcf8575_R1.digitalWrite(P6,LOW);

delay(50);

pcf8575_R1.digitalWrite(P7,LOW);

delay(50);

pcf8575_R1.digitalWrite(P8,LOW);

delay(50);

pcf8575_R1.digitalWrite(P9,LOW);

delay(50);

pcf8575_R1.digitalWrite(P10,LOW);

delay(50);

pcf8575_R1.digitalWrite(P11,LOW);

delay(50);

pcf8575_R1.digitalWrite(P12,LOW);

delay(50);

pcf8575_R1.digitalWrite(P13,LOW);

delay(50);

pcf8575_R1.digitalWrite(P14,LOW);

delay(50);

pcf8575_R1.digitalWrite(P15,LOW);

delay(50);

//R2 LOW------------------------

pcf8575_R2.digitalWrite(P0,LOW);

delay(50);

pcf8575_R2.digitalWrite(P1,LOW);

delay(50);

pcf8575_R2.digitalWrite(P2,LOW);

delay(50);

pcf8575_R2.digitalWrite(P3,LOW);

delay(50);

pcf8575_R2.digitalWrite(P4,LOW);

delay(50);

pcf8575_R2.digitalWrite(P5,LOW);

delay(50);

pcf8575_R2.digitalWrite(P6,LOW);

delay(50);

pcf8575_R2.digitalWrite(P7,LOW);

delay(50);

pcf8575_R2.digitalWrite(P8,LOW);

delay(50);

pcf8575_R2.digitalWrite(P9,LOW);

delay(50);

pcf8575_R2.digitalWrite(P10,LOW);

delay(50);

pcf8575_R2.digitalWrite(P11,LOW);

delay(50);

pcf8575_R2.digitalWrite(P12,LOW);

delay(50);

pcf8575_R2.digitalWrite(P13,LOW);

delay(50);

pcf8575_R2.digitalWrite(P14,LOW);

delay(50);

pcf8575_R2.digitalWrite(P15,LOW);

delay(50);

//R3 LOW------------------------

pcf8575_R3.digitalWrite(P0,LOW);

delay(50);

pcf8575_R3.digitalWrite(P1,LOW);

delay(50);

pcf8575_R3.digitalWrite(P2,LOW);

delay(50);

pcf8575_R3.digitalWrite(P3,LOW);

delay(50);

pcf8575_R3.digitalWrite(P4,LOW);

delay(50);

pcf8575_R3.digitalWrite(P5,LOW);

delay(50);

pcf8575_R3.digitalWrite(P6,LOW);

delay(50);

pcf8575_R3.digitalWrite(P7,LOW);

delay(50);

pcf8575_R3.digitalWrite(P8,LOW);

delay(50);

pcf8575_R3.digitalWrite(P9,LOW);

delay(50);

pcf8575_R3.digitalWrite(P10,LOW);

delay(50);

pcf8575_R3.digitalWrite(P11,LOW);

delay(50);

pcf8575_R3.digitalWrite(P12,LOW);

delay(50);

pcf8575_R3.digitalWrite(P13,LOW);

delay(50);

pcf8575_R3.digitalWrite(P14,LOW);

delay(50);

pcf8575_R3.digitalWrite(P15,LOW);

delay(50);

//R4 LOW------------------------

pcf8575_R4.digitalWrite(P0,LOW);

delay(50);

pcf8575_R4.digitalWrite(P1,LOW);

delay(50);

pcf8575_R4.digitalWrite(P2,LOW);

delay(50);

pcf8575_R4.digitalWrite(P3,LOW);

delay(50);

pcf8575_R4.digitalWrite(P4,LOW);

delay(50);

pcf8575_R4.digitalWrite(P5,LOW);

delay(50);

pcf8575_R4.digitalWrite(P6,LOW);

delay(50);

pcf8575_R4.digitalWrite(P7,LOW);

delay(50);

pcf8575_R4.digitalWrite(P8,LOW);

delay(50);

pcf8575_R4.digitalWrite(P9,LOW);

delay(50);

pcf8575_R4.digitalWrite(P10,LOW);

delay(50);

pcf8575_R4.digitalWrite(P11,LOW);

delay(50);

pcf8575_R4.digitalWrite(P12,LOW);

delay(50);

pcf8575_R4.digitalWrite(P13,LOW);

delay(50);

pcf8575_R4.digitalWrite(P14,LOW);

delay(50);

pcf8575_R4.digitalWrite(P15,LOW);

delay(50);

//R1 HIGH-----------------------

pcf8575_R1.digitalWrite(P0,HIGH);

delay(50);

pcf8575_R1.digitalWrite(P1,HIGH);

delay(50);

pcf8575_R1.digitalWrite(P2,HIGH);

delay(50);

pcf8575_R1.digitalWrite(P3,HIGH);

delay(50);

pcf8575_R1.digitalWrite(P4,HIGH);

delay(50);

pcf8575_R1.digitalWrite(P5,HIGH);

delay(50);

pcf8575_R1.digitalWrite(P6,HIGH);

delay(50);

pcf8575_R1.digitalWrite(P7,HIGH);

delay(50);

pcf8575_R1.digitalWrite(P8,HIGH);

delay(50);

pcf8575_R1.digitalWrite(P9,HIGH);

delay(50);

pcf8575_R1.digitalWrite(P10,HIGH);

delay(50);

pcf8575_R1.digitalWrite(P11,HIGH);

delay(50);

pcf8575_R1.digitalWrite(P12,HIGH);

delay(50);

pcf8575_R1.digitalWrite(P13,HIGH);

delay(50);

pcf8575_R1.digitalWrite(P14,HIGH);

delay(50);

pcf8575_R1.digitalWrite(P15,HIGH);

delay(50);

//R3 HIGH------------------------

pcf8575_R2.digitalWrite(P0,HIGH);

delay(50);

pcf8575_R2.digitalWrite(P1,HIGH);

delay(50);

pcf8575_R2.digitalWrite(P2,HIGH);

delay(50);

pcf8575_R2.digitalWrite(P3,HIGH);

delay(50);

pcf8575_R2.digitalWrite(P4,HIGH);

delay(50);

pcf8575_R2.digitalWrite(P5,HIGH);

delay(50);

pcf8575_R2.digitalWrite(P6,HIGH);

delay(50);

pcf8575_R2.digitalWrite(P7,HIGH);

delay(50);

pcf8575_R2.digitalWrite(P8,HIGH);

delay(50);

pcf8575_R2.digitalWrite(P9,HIGH);

delay(50);

pcf8575_R2.digitalWrite(P10,HIGH);

delay(50);

pcf8575_R2.digitalWrite(P11,HIGH);

delay(50);

pcf8575_R2.digitalWrite(P12,HIGH);

delay(50);

pcf8575_R2.digitalWrite(P13,HIGH);

delay(50);

pcf8575_R2.digitalWrite(P14,HIGH);

delay(50);

pcf8575_R2.digitalWrite(P15,HIGH);

delay(50);

//R3 HIGH-----------------------

pcf8575_R3.digitalWrite(P0,HIGH);

delay(50);

pcf8575_R3.digitalWrite(P1,HIGH);

delay(50);

pcf8575_R3.digitalWrite(P2,HIGH);

delay(50);

pcf8575_R3.digitalWrite(P3,HIGH);

delay(50);

pcf8575_R3.digitalWrite(P4,HIGH);

delay(50);

pcf8575_R3.digitalWrite(P5,HIGH);

delay(50);

pcf8575_R3.digitalWrite(P6,HIGH);

delay(50);

pcf8575_R3.digitalWrite(P7,HIGH);

delay(50);

pcf8575_R3.digitalWrite(P8,HIGH);

delay(50);

pcf8575_R3.digitalWrite(P9,HIGH);

delay(50);

pcf8575_R3.digitalWrite(P10,HIGH);

delay(50);

pcf8575_R3.digitalWrite(P11,HIGH);

delay(50);

pcf8575_R3.digitalWrite(P12,HIGH);

delay(50);

pcf8575_R3.digitalWrite(P13,HIGH);

delay(50);

pcf8575_R3.digitalWrite(P14,HIGH);

delay(50);

pcf8575_R3.digitalWrite(P15,HIGH);

delay(50);

//R4 HIGH------------------------

pcf8575_R4.digitalWrite(P0,HIGH);

delay(50);

pcf8575_R4.digitalWrite(P1,HIGH);

delay(50);

pcf8575_R4.digitalWrite(P2,HIGH);

delay(50);

pcf8575_R4.digitalWrite(P3,HIGH);

delay(50);

pcf8575_R4.digitalWrite(P4,HIGH);

delay(50);

pcf8575_R4.digitalWrite(P5,HIGH);

delay(50);

pcf8575_R4.digitalWrite(P6,HIGH);

delay(50);

pcf8575_R4.digitalWrite(P7,HIGH);

delay(50);

pcf8575_R4.digitalWrite(P8,HIGH);

delay(50);

pcf8575_R4.digitalWrite(P9,HIGH);

delay(50);

pcf8575_R4.digitalWrite(P10,HIGH);

delay(50);

pcf8575_R4.digitalWrite(P11,HIGH);

delay(50);

pcf8575_R4.digitalWrite(P12,HIGH);

delay(50);

pcf8575_R4.digitalWrite(P13,HIGH);

delay(50);

pcf8575_R4.digitalWrite(P14,HIGH);

delay(50);

pcf8575_R4.digitalWrite(P15,HIGH);

delay(50);

*/

}

Attached Files
.zip

KC868-A64-PCF8575-DO.zip (Size: 1.48 KB / Downloads: 230)

[Arduino IDE demo source code for KC868-A64]--#03-ADC_code

Posted by: KinCony Support - 05-12-2022, 07:20 AM - Forum: KC868-A64 - No Replies

[Arduino IDE demo source code for KC868-A64]--#03-ADC_code

Code:
/*www.kincony.com*/

/*KC868-A64 Code of ADC_INPUT */

#include "Arduino.h"

#define ANALOG_A1   39

#define ANALOG_A2   34

#define ANALOG_A3   36

#define ANALOG_A4   35

void setup()

{

    Serial.begin(115200);

    delay(1000);

  pinMode(ANALOG_A1,INPUT);

  pinMode(ANALOG_A2,INPUT);

  pinMode(ANALOG_A3,INPUT);

  pinMode(ANALOG_A4,INPUT);

}

void loop()

{

  delay(500);

  if(analogRead(ANALOG_A1)!=0)  {Serial.printf("Current Reading A1 on Pin(%d)=%d\n",ANALOG_A1,analogRead(ANALOG_A1));}

  if(analogRead(ANALOG_A2)!=0)  {Serial.printf("Current Reading A2 on Pin(%d)=%d\n",ANALOG_A2,analogRead(ANALOG_A2));}

  if(analogRead(ANALOG_A3)!=0)  {Serial.printf("Current Reading A3 on Pin(%d)=%d\n",ANALOG_A3,analogRead(ANALOG_A3));}

  if(analogRead(ANALOG_A4)!=0)  {Serial.printf("Current Reading A4 on Pin(%d)=%d\n",ANALOG_A4,analogRead(ANALOG_A4));}

}

Attached Files
.zip

KC868-A64-ADC_INOUT.zip (Size: 686 bytes / Downloads: 230)

[Arduino IDE demo source code for KC868-A64]--#02-LAN8720_UDP_code

Posted by: KinCony Support - 05-12-2022, 07:04 AM - Forum: KC868-A64 - No Replies

[Arduino IDE demo source code for KC868-A64]--#02-LAN8720_UDP_code

Code:
/*www.kincony.com*/

/*KC868-A64 code of LAN8720 */

#include <ETH.h>

#include <WiFiUdp.h>

#define ETH_ADDR        0

#define ETH_POWER_PIN  -1

#define ETH_MDC_PIN    23

#define ETH_MDIO_PIN   18

#define ETH_TYPE       ETH_PHY_LAN8720

#define ETH_CLK_MODE   ETH_CLOCK_GPIO17_OUT

WiFiUDP Udp;                      //Create UDP object

unsigned int localUdpPort = 4196; //local port

// Set it based on the IP address of the router

IPAddress local_ip(192, 168, 1, 200);

IPAddress gateway(192, 168, 1, 1);

IPAddress subnet(255, 255, 255, 0);

IPAddress dns(192, 168, 1, 1);

void setup()

{

  Serial.begin(115200);

  Serial.println();

  ETH.begin(ETH_ADDR, ETH_POWER_PIN, ETH_MDC_PIN, ETH_MDIO_PIN, ETH_TYPE, ETH_CLK_MODE); //start with ETH

  // write confir for static IP, gateway,subnet,dns1,dns2

  if (ETH.config(local_ip, gateway, subnet, dns, dns) == false) {

    Serial.println("LAN8720 Configuration failed.");

  }else{Serial.println("LAN8720 Configuration success.");}

  Serial.println("Connected");

  Serial.print("IP Address:");

  Serial.println(ETH.localIP());

  Udp.begin(localUdpPort); //begin UDP listener

}

void loop()

{

  int packetSize = Udp.parsePacket(); //get package size

  if (packetSize)                     //if have received data

  {

    char buf[packetSize];

    Udp.read(buf, packetSize); //read current data

    Serial.println();

    Serial.print("Received: ");

    Serial.println(buf);

    Serial.print("From IP: ");

    Serial.println(Udp.remoteIP());

    Serial.print("From Port: ");

    Serial.println(Udp.remotePort());

    Udp.beginPacket(Udp.remoteIP(), Udp.remotePort()); //ready to send data

    Udp.print("Received: ");

    Udp.write((const uint8_t*)buf, packetSize); //copy data to sender buffer

    Udp.endPacket();            //send data

  }

}

Attached Files
.zip

KC868-A64-LAN8720.zip (Size: 1.29 KB / Downloads: 249)
.zip

NetAssist.zip (Size: 481.86 KB / Downloads: 229)

[Arduino IDE demo source code for KC868-A64]--#01-RS485_code

Posted by: KinCony Support - 05-12-2022, 06:56 AM - Forum: KC868-A64 - No Replies

[Arduino IDE demo source code for KC868-A64]--#01-RS485_code

Code:
/*WWW.KINCONY.COM*/

/*KC868-A64 code of RS485 */

void setup() {

Serial2.begin(9600,SERIAL_8N1,13,14);  //  IO13   485RX   IO14 485TX

}

void loop() {

Serial2.println("KinCony ACBDEFG"); // Enter your print string

delay(1500);

}

Attached Files
.zip

KC868-A64-RS485.zip (Size: 697 bytes / Downloads: 256)

KC868-A64 configure for ESPhome

Posted by: admin - 05-12-2022, 01:05 AM - Forum: KC868-A64 - Replies (10)

esphome:
name: a64
platform: ESP32
board: esp32dev

# Enable logging
logger:

# Enable Home Assistant API
api:

# Example configuration entry
i2c:
- id: bus_a
sda: 5
scl: 16
scan: true
frequency: 400kHz
- id: bus_b
sda: 15
scl: 4
scan: true
frequency: 400kHz

# Example configuration entry
ethernet:
type: LAN8720
mdc_pin: GPIO23
mdio_pin: GPIO18
clk_mode: GPIO17_OUT
phy_addr: 0

# Optional manual IP
manual_ip:
static_ip: 192.168.1.198
gateway: 192.168.1.1
subnet: 255.255.255.0

# Example configuration entry
pcf8574:
- id: 'pcf8574_hub_out_1' # for output channel 1-16
i2c_id: bus_a
address: 0x24
pcf8575: true

- id: 'pcf8574_hub_out_2' # for output channel 17-32
i2c_id: bus_a
address: 0x25
pcf8575: true

- id: 'pcf8574_hub_out_3' # for output channel 33-48
i2c_id: bus_a
address: 0x21
pcf8575: true

- id: 'pcf8574_hub_out_4' # for output channel 49-64
i2c_id: bus_a
address: 0x22
pcf8575: true

- id: 'pcf8574_hub_in_1' # for a64--input channel 1-16
i2c_id: bus_b
address: 0x24
pcf8575: true

- id: 'pcf8574_hub_in_2' # for a64--input channel 17-32
i2c_id: bus_b
address: 0x25
pcf8575: true

- id: 'pcf8574_hub_in_3' # for a64--input channel 33-48
i2c_id: bus_b
address: 0x21
pcf8575: true

- id: 'pcf8574_hub_in_4' # for a64--input channel 49-64
i2c_id: bus_b
address: 0x22
pcf8575: true

# Individual outputs
switch:
- platform: gpio
name: "a64--light1"
pin:
pcf8574: pcf8574_hub_out_1
number: 0
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light2"
pin:
pcf8574: pcf8574_hub_out_1
number: 1
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light3"
pin:
pcf8574: pcf8574_hub_out_1
number: 2
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light4"
pin:
pcf8574: pcf8574_hub_out_1
number: 3
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light5"
pin:
pcf8574: pcf8574_hub_out_1
number: 4
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light6"
pin:
pcf8574: pcf8574_hub_out_1
number: 5
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light7"
pin:
pcf8574: pcf8574_hub_out_1
number: 6
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light8"
pin:
pcf8574: pcf8574_hub_out_1
number: 7
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light9"
pin:
pcf8574: pcf8574_hub_out_1
number: 8
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light10"
pin:
pcf8574: pcf8574_hub_out_1
number: 9
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light11"
pin:
pcf8574: pcf8574_hub_out_1
number: 10
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light12"
pin:
pcf8574: pcf8574_hub_out_1
number: 11
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light13"
pin:
pcf8574: pcf8574_hub_out_1
number: 12
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light14"
pin:
pcf8574: pcf8574_hub_out_1
number: 13
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light15"
pin:
pcf8574: pcf8574_hub_out_1
number: 14
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light16"
pin:
pcf8574: pcf8574_hub_out_1
number: 15
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light17"
pin:
pcf8574: pcf8574_hub_out_2
number: 0
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light18"
pin:
pcf8574: pcf8574_hub_out_2
number: 1
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light19"
pin:
pcf8574: pcf8574_hub_out_2
number: 2
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light20"
pin:
pcf8574: pcf8574_hub_out_2
number: 3
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light21"
pin:
pcf8574: pcf8574_hub_out_2
number: 4
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light22"
pin:
pcf8574: pcf8574_hub_out_2
number: 5
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light23"
pin:
pcf8574: pcf8574_hub_out_2
number: 6
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light24"
pin:
pcf8574: pcf8574_hub_out_2
number: 7
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light25"
pin:
pcf8574: pcf8574_hub_out_2
number: 8
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light26"
pin:
pcf8574: pcf8574_hub_out_2
number: 9
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light27"
pin:
pcf8574: pcf8574_hub_out_2
number: 10
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light28"
pin:
pcf8574: pcf8574_hub_out_2
number: 11
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light29"
pin:
pcf8574: pcf8574_hub_out_2
number: 12
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light30"
pin:
pcf8574: pcf8574_hub_out_2
number: 13
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light31"
pin:
pcf8574: pcf8574_hub_out_2
number: 14
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light32"
pin:
pcf8574: pcf8574_hub_out_2
number: 15
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light33"
pin:
pcf8574: pcf8574_hub_out_3
number: 0
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light34"
pin:
pcf8574: pcf8574_hub_out_3
number: 1
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light35"
pin:
pcf8574: pcf8574_hub_out_3
number: 2
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light36"
pin:
pcf8574: pcf8574_hub_out_3
number: 3
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light37"
pin:
pcf8574: pcf8574_hub_out_3
number: 4
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light38"
pin:
pcf8574: pcf8574_hub_out_3
number: 5
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light39"
pin:
pcf8574: pcf8574_hub_out_3
number: 6
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light40"
pin:
pcf8574: pcf8574_hub_out_3
number: 7
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light41"
pin:
pcf8574: pcf8574_hub_out_3
number: 8
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light42"
pin:
pcf8574: pcf8574_hub_out_3
number: 9
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light43"
pin:
pcf8574: pcf8574_hub_out_3
number: 10
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light44"
pin:
pcf8574: pcf8574_hub_out_3
number: 11
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light45"
pin:
pcf8574: pcf8574_hub_out_3
number: 12
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light46"
pin:
pcf8574: pcf8574_hub_out_3
number: 13
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light47"
pin:
pcf8574: pcf8574_hub_out_3
number: 14
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light48"
pin:
pcf8574: pcf8574_hub_out_3
number: 15
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light49"
pin:
pcf8574: pcf8574_hub_out_4
number: 0
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light50"
pin:
pcf8574: pcf8574_hub_out_4
number: 1
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light51"
pin:
pcf8574: pcf8574_hub_out_4
number: 2
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light52"
pin:
pcf8574: pcf8574_hub_out_4
number: 3
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light53"
pin:
pcf8574: pcf8574_hub_out_4
number: 4
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light54"
pin:
pcf8574: pcf8574_hub_out_4
number: 5
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light55"
pin:
pcf8574: pcf8574_hub_out_4
number: 6
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light56"
pin:
pcf8574: pcf8574_hub_out_4
number: 7
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light57"
pin:
pcf8574: pcf8574_hub_out_4
number: 8
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light58"
pin:
pcf8574: pcf8574_hub_out_4
number: 9
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light59"
pin:
pcf8574: pcf8574_hub_out_4
number: 10
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light60"
pin:
pcf8574: pcf8574_hub_out_4
number: 11
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light61"
pin:
pcf8574: pcf8574_hub_out_4
number: 12
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light62"
pin:
pcf8574: pcf8574_hub_out_4
number: 13
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light63"
pin:
pcf8574: pcf8574_hub_out_4
number: 14
mode: OUTPUT
inverted: true

- platform: gpio
name: "a64--light64"
pin:
pcf8574: pcf8574_hub_out_4
number: 15
mode: OUTPUT
inverted: true

# Individual inputs
binary_sensor:
- platform: gpio
name: "a64--input1"
pin:
pcf8574: pcf8574_hub_in_1
number: 0
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input2"
pin:
pcf8574: pcf8574_hub_in_1
number: 1
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input3"
pin:
pcf8574: pcf8574_hub_in_1
number: 2
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input4"
pin:
pcf8574: pcf8574_hub_in_1
number: 3
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input5"
pin:
pcf8574: pcf8574_hub_in_1
number: 4
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input6"
pin:
pcf8574: pcf8574_hub_in_1
number: 5
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input7"
pin:
pcf8574: pcf8574_hub_in_1
number: 6
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input8"
pin:
pcf8574: pcf8574_hub_in_1
number: 7
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input9"
pin:
pcf8574: pcf8574_hub_in_1
number: 8
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input10"
pin:
pcf8574: pcf8574_hub_in_1
number: 9
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input11"
pin:
pcf8574: pcf8574_hub_in_1
number: 10
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input12"
pin:
pcf8574: pcf8574_hub_in_1
number: 11
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input13"
pin:
pcf8574: pcf8574_hub_in_1
number: 12
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input14"
pin:
pcf8574: pcf8574_hub_in_1
number: 13
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input15"
pin:
pcf8574: pcf8574_hub_in_1
number: 14
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input16"
pin:
pcf8574: pcf8574_hub_in_1
number: 15
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input17"
pin:
pcf8574: pcf8574_hub_in_2
number: 0
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input18"
pin:
pcf8574: pcf8574_hub_in_2
number: 1
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input19"
pin:
pcf8574: pcf8574_hub_in_2
number: 2
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input20"
pin:
pcf8574: pcf8574_hub_in_2
number: 3
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input21"
pin:
pcf8574: pcf8574_hub_in_2
number: 4
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input22"
pin:
pcf8574: pcf8574_hub_in_2
number: 5
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input23"
pin:
pcf8574: pcf8574_hub_in_2
number: 6
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input24"
pin:
pcf8574: pcf8574_hub_in_2
number: 7
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input25"
pin:
pcf8574: pcf8574_hub_in_2
number: 8
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input26"
pin:
pcf8574: pcf8574_hub_in_2
number: 9
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input27"
pin:
pcf8574: pcf8574_hub_in_2
number: 10
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input28"
pin:
pcf8574: pcf8574_hub_in_2
number: 11
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input29"
pin:
pcf8574: pcf8574_hub_in_2
number: 12
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input30"
pin:
pcf8574: pcf8574_hub_in_2
number: 13
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input31"
pin:
pcf8574: pcf8574_hub_in_2
number: 14
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input32"
pin:
pcf8574: pcf8574_hub_in_2
number: 15
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input33"
pin:
pcf8574: pcf8574_hub_in_3
number: 0
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input34"
pin:
pcf8574: pcf8574_hub_in_3
number: 1
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input35"
pin:
pcf8574: pcf8574_hub_in_3
number: 2
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input36"
pin:
pcf8574: pcf8574_hub_in_3
number: 3
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input37"
pin:
pcf8574: pcf8574_hub_in_3
number: 4
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input38"
pin:
pcf8574: pcf8574_hub_in_3
number: 5
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input39"
pin:
pcf8574: pcf8574_hub_in_3
number: 6
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input40"
pin:
pcf8574: pcf8574_hub_in_3
number: 7
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input41"
pin:
pcf8574: pcf8574_hub_in_3
number: 8
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input42"
pin:
pcf8574: pcf8574_hub_in_3
number: 9
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input43"
pin:
pcf8574: pcf8574_hub_in_3
number: 10
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input44"
pin:
pcf8574: pcf8574_hub_in_3
number: 11
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input45"
pin:
pcf8574: pcf8574_hub_in_3
number: 12
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input46"
pin:
pcf8574: pcf8574_hub_in_3
number: 13
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input47"
pin:
pcf8574: pcf8574_hub_in_3
number: 14
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input48"
pin:
pcf8574: pcf8574_hub_in_3
number: 15
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input49"
pin:
pcf8574: pcf8574_hub_in_4
number: 0
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input50"
pin:
pcf8574: pcf8574_hub_in_4
number: 1
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input51"
pin:
pcf8574: pcf8574_hub_in_4
number: 2
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input52"
pin:
pcf8574: pcf8574_hub_in_4
number: 3
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input53"
pin:
pcf8574: pcf8574_hub_in_4
number: 4
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input54"
pin:
pcf8574: pcf8574_hub_in_4
number: 5
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input55"
pin:
pcf8574: pcf8574_hub_in_4
number: 6
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input56"
pin:
pcf8574: pcf8574_hub_in_4
number: 7
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input57"
pin:
pcf8574: pcf8574_hub_in_4
number: 8
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input58"
pin:
pcf8574: pcf8574_hub_in_4
number: 9
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input59"
pin:
pcf8574: pcf8574_hub_in_4
number: 10
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input60"
pin:
pcf8574: pcf8574_hub_in_4
number: 11
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input61"
pin:
pcf8574: pcf8574_hub_in_4
number: 12
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input62"
pin:
pcf8574: pcf8574_hub_in_4
number: 13
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input63"
pin:
pcf8574: pcf8574_hub_in_4
number: 14
mode: INPUT
inverted: true

- platform: gpio
name: "a64--input64"
pin:
pcf8574: pcf8574_hub_in_4
number: 15
mode: INPUT
inverted: true

# Example configuration entry
sensor:
- platform: adc
pin: 39
name: "a64--analog--1"
update_interval: 20s
attenuation: 11db

- platform: adc
pin: 34
name: "a64--analog--2"
update_interval: 20s
attenuation: 11db

- platform: adc
pin: 36
name: "a64--analog--3"
update_interval: 20s
attenuation: 11db

- platform: adc
pin: 35
name: "a64--analog--4"
update_interval: 20s
attenuation: 11db

Attached Files
.txt

KC868-A64-ESPHome_PCF8575_Analog.txt (Size: 21.08 KB / Downloads: 455)

KC868-A64 ESP32 I/O pin define

Posted by: admin - 05-12-2022, 01:03 AM - Forum: KC868-A64 - No Replies

#define ANALOG_A1 GPIO39
#define ANALOG_A2 GPIO34
#define ANALOG_A3 GPIO36
#define ANALOG_A4 GPIO35

IIC Bus-1:A

SDA-A:GPIO5
SCL-A:GPIO16

PCF8575:U143 (relay1-16): 100 100 = 0x24
PCF8575:U145 (relay17-32): 100 101 = 0x25
PCF8575:U147 (relay33-48): 100 001 = 0x21
PCF8575:U149 (relay49-64): 100 010 = 0x22

IIC Bus-2:B
SDA-B:GPIO15
SCL-B:GPIO4

PCF8575:U14 (DI1-16): 100 100 = 0x24
PCF8575:U31 (DI17-32): 100 101 = 0x25
PCF8575:U56 (DI33-48): 100 001 = 0x21
PCF8575:U57 (DI49-64): 100 010 = 0x22

-----------------

Ethernet (LAN8720) I/O define:

#define ETH_ADDR 0
#define ETH_POWER_PIN -1
#define ETH_MDC_PIN 23
#define ETH_MDIO_PIN 18
#define ETH_TYPE ETH_PHY_LAN8720
#define ETH_CLK_MODE ETH_CLOCK_GPIO17_OUT

--------------------

RS485:
RXD:GPIO13
TXD:GPIO14

Extend serial port (3.3v TTL level):
RXD:GPIO32
TXD:GPIO33

KC868-UAIR ESPHOME Config for IR and RF

Posted by: dmshimself - 05-10-2022, 09:25 PM - Forum: KC868-Uair - Replies (34)

I've recently received a bare board for a KC868-UAIR as the original shipped with the tower case didn't work. I've got the new board working with ESPHOME and Home Assistant using the config I was given and that works fine. But the config didn't cover the buzzer, the IR receiver/transmitter and RF receiver/transmitter. These are advertised features, so I want to make sure the new board works. I got the buzzer working ok, but I'm struggling with the IR and RF.

I've been asked by the supplier to make a post here, so here it is :-)

What I've done so far is to try to read IR codes using the guide is ESPHOME located here:
https://esphome.io/components/remote_tra...p-infrared

Using the tech info on the KC868-UAIR I've added the following to my ESPHOME confg given the data located here:
https://www.kincony.com/forum/showthread.php?tid=1438

remote_receiver:
pin: GPIO19
dump: all

With that, the ESPHOME log says that the pin is high initially and that I should invert it. Anyway, I placed the TV remote close the front of the board where the IR receiver is next to the USB ports and no data was received. The TV did receive them as I have the TV directly behind the board and the TV worked (volume up/down)

So I inverted the pin with

remote_receiver:
pin:
number: GPIO19
inverted: true
dump: all

and while ESPHOME no longer suggested I needed to invert the pin, I still do not get any data being dumped out to the console. I can see other messages like the temperature changes just fine.

Has anyone got a config that works for these extra devices as access to these was an important reason for my purchase?

[Arduino IDE demo source code for KC868-SERVER]--#05-WS2812B LED_code

Posted by: KinCony Support - 05-06-2022, 03:28 AM - Forum: KC868-Server Raspberry Pi4 local server - No Replies

[Arduino IDE demo source code for KC868-SERVER]--#05-WS2812B LED_code

Code:
#include <Adafruit_NeoPixel.h>

Adafruit_NeoPixel rgb_display_4 = Adafruit_NeoPixel(5,4,NEO_GRB + NEO_KHZ800);

// LED numbers is 5    led connect to IO4

void setup(){

  rgb_display_4.begin();

}

void loop(){

  rgb_display_4.setPixelColor((1)-1, (0xff0000)); //LED 1 RED

  rgb_display_4.setPixelColor((2)-1, (0x3333ff)); //LED 2 BLUE

  rgb_display_4.setPixelColor((3)-1, (0xffff33)); //LED 3 YELLOW

  rgb_display_4.setPixelColor((4)-1, (0x33ff33)); //LED 4 GREEN

  rgb_display_4.setPixelColor((5)-1, (0xcc33cc)); //LED 5 PURPLE

  rgb_display_4.show();

}

Install "Adafruit_NeoPixel"first

KC868-D8

Posted by: Dm81 - 05-05-2022, 09:22 PM - Forum: KC868-HxB series Smart Controller - Replies (10)

	Hello I have a question about KC868-D8 in server mode Is it correct that I don't receive command if I close any digital input on the board? I think that a client connected to the KC868-D8 should be receive a command (or string) about output variation thank you

KC868-COLB/BS/Mini V1.12 new firmware and PC software update

Posted by: admin - 05-05-2022, 02:00 AM - Forum: News - Replies (2)

improvement:

1. support one KC868-COLB/COLBS/COLB-Mini control multi relay board by "HTTP" command.
2. support create customsize command by "HTTP command".
3. translate "DEBUG" mode window to English language.

KC868-COLB V1.12 firmware download:

.zip AD_COLB_V1_1_12_220503.zip (Size: 41.92 KB / Downloads: 284)

New PC software Kincony_SCB_V1.0.410.504 download:

.zip Kincony_SCB_V1.0.410.504.zip (Size: 7.3 MB / Downloads: 409)

Attached Files Thumbnail(s)

Pages (254): « Previous 1 … 188 189 190 191 192 193 194 195 196 197 198 199 200 201 202 203 204 205 206 207 208 … 254 Next »

Login
Username:
Password:	Lost Password?
	Remember me
