[Arduino IDE demo source code for KC868-A128]--#01--ADC_INOUT code

Posted by: KinCony Support - 08-05-2022, 02:07 AM - Forum: KC868-A128 - No Replies

[Arduino IDE demo source code for KC868-A128]--#01--ADC_INOUT code

Code:
#include "Arduino.h"

#define ANALOG_A1   39

#define ANALOG_A2   34

#define ANALOG_A3   36

#define ANALOG_A4   35

void setup()

{

    Serial.begin(115200);

    delay(1000);

  pinMode(ANALOG_A1,INPUT);

  pinMode(ANALOG_A2,INPUT);

  pinMode(ANALOG_A3,INPUT);

  pinMode(ANALOG_A4,INPUT);

}

void loop()

{

  delay(500);

  Serial.printf("Current Reading A1 on Pin(%d)=%d\n",ANALOG_A1,analogRead(ANALOG_A1));

  Serial.printf("Current Reading A2 on Pin(%d)=%d\n",ANALOG_A2,analogRead(ANALOG_A2));

  Serial.printf("Current Reading A3 on Pin(%d)=%d\n",ANALOG_A3,analogRead(ANALOG_A3));

  Serial.printf("Current Reading A4 on Pin(%d)=%d\n",ANALOG_A4,analogRead(ANALOG_A4));

}

led doesn't light up

Posted by: 2sdaymars - 08-05-2022, 01:38 AM - Forum: KC868-A16 - Replies (7)

I bought it and used it, but it doesn't work.

I put the code on esphome and turned on the switch, but the led doesn't light up.

i use this code

esphome:
name: a16

platform: ESP32

board: esp32dev

# Example configuration entry for ESP32

i2c:

sda: 4

scl: 5

scan: true

id: bus_a

# Example configuration entry

pcf8574:

- id: 'pcf8574_hub_out_1' # for output channel 1-8

address: 0x24

- id: 'pcf8574_hub_out_2' # for output channel 9-16

address: 0x25

- id: 'pcf8574_hub_in_1' # for input channel 1-8

address: 0x21

- id: 'pcf8574_hub_in_2' # for input channel 9-16

address: 0x22

# Individual outputs

switch:

- platform: gpio

name: "light1"

pin:

pcf8574: pcf8574_hub_out_1

# Use pin number 0

number: 0

# One of INPUT or OUTPUT

mode: OUTPUT

inverted: false

- platform: gpio

name: "light9"

pin:

pcf8574: pcf8574_hub_out_2

# Use pin number 0

number: 0

# One of INPUT or OUTPUT

mode: OUTPUT

inverted: false

binary_sensor:

- platform: gpio

name: "input1"

pin:

pcf8574: pcf8574_hub_in_1

# Use pin number 0

number: 0

# One of INPUT or OUTPUT

mode: INPUT

inverted: false

- platform: gpio

name: "input9"

pin:

pcf8574: pcf8574_hub_in_2

# Use pin number 0

number: 0

# One of INPUT or OUTPUT

mode: INPUT
inverted: false

# Enable logging

logger:

# Enable Home Assistant API

api:

encryption:

key: "xxxxxxxxxxxxxxxxxxxxxxxxxxxxx"

ota:

password: "xxxxxxxxxxxxxxxxx"

wifi:

ssid: !secret wifi_ssid

password: !secret wifi_password

# Enable fallback hotspot (captive portal) in case wifi connection fails

ap:

ssid: "xxxxxxxxxxxxxxx"

password: "xxxxxxxx"

captive_portal:

KC868-A128 configure for ESPhome

Posted by: admin - 08-04-2022, 09:47 PM - Forum: KC868-A128 - Replies (14)

.txt KC868-A128-ESPHome_PCF8575_Analog.txt (Size: 40.53 KB / Downloads: 461)

esphome:
name: a128
platform: ESP32
board: esp32dev

# Enable logging
logger:

# Enable Home Assistant API
api:

# Example configuration entry
i2c:
- id: bus_a
sda: 5
scl: 16
scan: true
frequency: 400kHz
- id: bus_b
sda: 15
scl: 4
scan: true
frequency: 400kHz

# Example configuration entry
ethernet:
type: LAN8720
mdc_pin: GPIO23
mdio_pin: GPIO18
clk_mode: GPIO17_OUT
phy_addr: 0

# Optional manual IP
manual_ip:
static_ip: 192.168.1.198
gateway: 192.168.1.1
subnet: 255.255.255.0

# Example configuration entry
pcf8574:
- id: 'pcf8574_hub_out_1' # for output channel 1-16
i2c_id: bus_a
address: 0x24
pcf8575: true

- id: 'pcf8574_hub_out_2' # for output channel 17-32
i2c_id: bus_a
address: 0x25
pcf8575: true

- id: 'pcf8574_hub_out_3' # for output channel 33-48
i2c_id: bus_a
address: 0x21
pcf8575: true

- id: 'pcf8574_hub_out_4' # for output channel 49-64
i2c_id: bus_a
address: 0x22
pcf8575: true

- id: 'pcf8574_hub_out_5' # for output channel 65-80
i2c_id: bus_a
address: 0x26
pcf8575: true

- id: 'pcf8574_hub_out_6' # for output channel 81-96
i2c_id: bus_a
address: 0x27
pcf8575: true

- id: 'pcf8574_hub_out_7' # for output channel 97-112
i2c_id: bus_a
address: 0x20
pcf8575: true

- id: 'pcf8574_hub_out_8' # for output channel 113-128
i2c_id: bus_a
address: 0x23
pcf8575: true

- id: 'pcf8574_hub_in_1' # for a128-input channel 1-16
i2c_id: bus_b
address: 0x24
pcf8575: true

- id: 'pcf8574_hub_in_2' # for a128-input channel 17-32
i2c_id: bus_b
address: 0x25
pcf8575: true

- id: 'pcf8574_hub_in_3' # for a128-input channel 33-48
i2c_id: bus_b
address: 0x21
pcf8575: true

- id: 'pcf8574_hub_in_4' # for a128-input channel 49-64
i2c_id: bus_b
address: 0x22
pcf8575: true

- id: 'pcf8574_hub_in_5' # for a128-input channel 65-80
i2c_id: bus_b
address: 0x26
pcf8575: true

- id: 'pcf8574_hub_in_6' # for a128-input channel 81-96
i2c_id: bus_b
address: 0x27
pcf8575: true

- id: 'pcf8574_hub_in_7' # for a128-input channel 97-112
i2c_id: bus_b
address: 0x20
pcf8575: true

- id: 'pcf8574_hub_in_8' # for a128-input channel 113-128
i2c_id: bus_b
address: 0x23
pcf8575: true

# Individual outputs
switch:
- platform: gpio
name: "a128-light1"
pin:
pcf8574: pcf8574_hub_out_1
number: 0
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light2"
pin:
pcf8574: pcf8574_hub_out_1
number: 1
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light3"
pin:
pcf8574: pcf8574_hub_out_1
number: 2
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light4"
pin:
pcf8574: pcf8574_hub_out_1
number: 3
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light5"
pin:
pcf8574: pcf8574_hub_out_1
number: 4
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light6"
pin:
pcf8574: pcf8574_hub_out_1
number: 5
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light7"
pin:
pcf8574: pcf8574_hub_out_1
number: 6
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light8"
pin:
pcf8574: pcf8574_hub_out_1
number: 7
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light9"
pin:
pcf8574: pcf8574_hub_out_1
number: 8
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light10"
pin:
pcf8574: pcf8574_hub_out_1
number: 9
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light11"
pin:
pcf8574: pcf8574_hub_out_1
number: 10
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light12"
pin:
pcf8574: pcf8574_hub_out_1
number: 11
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light13"
pin:
pcf8574: pcf8574_hub_out_1
number: 12
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light14"
pin:
pcf8574: pcf8574_hub_out_1
number: 13
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light15"
pin:
pcf8574: pcf8574_hub_out_1
number: 14
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light16"
pin:
pcf8574: pcf8574_hub_out_1
number: 15
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light17"
pin:
pcf8574: pcf8574_hub_out_2
number: 0
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light18"
pin:
pcf8574: pcf8574_hub_out_2
number: 1
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light19"
pin:
pcf8574: pcf8574_hub_out_2
number: 2
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light20"
pin:
pcf8574: pcf8574_hub_out_2
number: 3
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light21"
pin:
pcf8574: pcf8574_hub_out_2
number: 4
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light22"
pin:
pcf8574: pcf8574_hub_out_2
number: 5
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light23"
pin:
pcf8574: pcf8574_hub_out_2
number: 6
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light24"
pin:
pcf8574: pcf8574_hub_out_2
number: 7
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light25"
pin:
pcf8574: pcf8574_hub_out_2
number: 8
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light26"
pin:
pcf8574: pcf8574_hub_out_2
number: 9
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light27"
pin:
pcf8574: pcf8574_hub_out_2
number: 10
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light28"
pin:
pcf8574: pcf8574_hub_out_2
number: 11
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light29"
pin:
pcf8574: pcf8574_hub_out_2
number: 12
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light30"
pin:
pcf8574: pcf8574_hub_out_2
number: 13
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light31"
pin:
pcf8574: pcf8574_hub_out_2
number: 14
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light32"
pin:
pcf8574: pcf8574_hub_out_2
number: 15
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light33"
pin:
pcf8574: pcf8574_hub_out_3
number: 0
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light34"
pin:
pcf8574: pcf8574_hub_out_3
number: 1
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light35"
pin:
pcf8574: pcf8574_hub_out_3
number: 2
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light36"
pin:
pcf8574: pcf8574_hub_out_3
number: 3
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light37"
pin:
pcf8574: pcf8574_hub_out_3
number: 4
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light38"
pin:
pcf8574: pcf8574_hub_out_3
number: 5
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light39"
pin:
pcf8574: pcf8574_hub_out_3
number: 6
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light40"
pin:
pcf8574: pcf8574_hub_out_3
number: 7
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light41"
pin:
pcf8574: pcf8574_hub_out_3
number: 8
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light42"
pin:
pcf8574: pcf8574_hub_out_3
number: 9
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light43"
pin:
pcf8574: pcf8574_hub_out_3
number: 10
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light44"
pin:
pcf8574: pcf8574_hub_out_3
number: 11
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light45"
pin:
pcf8574: pcf8574_hub_out_3
number: 12
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light46"
pin:
pcf8574: pcf8574_hub_out_3
number: 13
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light47"
pin:
pcf8574: pcf8574_hub_out_3
number: 14
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light48"
pin:
pcf8574: pcf8574_hub_out_3
number: 15
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light49"
pin:
pcf8574: pcf8574_hub_out_4
number: 0
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light50"
pin:
pcf8574: pcf8574_hub_out_4
number: 1
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light51"
pin:
pcf8574: pcf8574_hub_out_4
number: 2
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light52"
pin:
pcf8574: pcf8574_hub_out_4
number: 3
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light53"
pin:
pcf8574: pcf8574_hub_out_4
number: 4
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light54"
pin:
pcf8574: pcf8574_hub_out_4
number: 5
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light55"
pin:
pcf8574: pcf8574_hub_out_4
number: 6
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light56"
pin:
pcf8574: pcf8574_hub_out_4
number: 7
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light57"
pin:
pcf8574: pcf8574_hub_out_4
number: 8
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light58"
pin:
pcf8574: pcf8574_hub_out_4
number: 9
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light59"
pin:
pcf8574: pcf8574_hub_out_4
number: 10
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light60"
pin:
pcf8574: pcf8574_hub_out_4
number: 11
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light61"
pin:
pcf8574: pcf8574_hub_out_4
number: 12
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light62"
pin:
pcf8574: pcf8574_hub_out_4
number: 13
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light63"
pin:
pcf8574: pcf8574_hub_out_4
number: 14
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light64"
pin:
pcf8574: pcf8574_hub_out_4
number: 15
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light65"
pin:
pcf8574: pcf8574_hub_out_5
number: 0
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light66"
pin:
pcf8574: pcf8574_hub_out_5
number: 1
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light67"
pin:
pcf8574: pcf8574_hub_out_5
number: 2
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light68"
pin:
pcf8574: pcf8574_hub_out_5
number: 3
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light69"
pin:
pcf8574: pcf8574_hub_out_5
number: 4
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light70"
pin:
pcf8574: pcf8574_hub_out_5
number: 5
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light71"
pin:
pcf8574: pcf8574_hub_out_5
number: 6
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light72"
pin:
pcf8574: pcf8574_hub_out_5
number: 7
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light73"
pin:
pcf8574: pcf8574_hub_out_5
number: 8
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light74"
pin:
pcf8574: pcf8574_hub_out_5
number: 9
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light75"
pin:
pcf8574: pcf8574_hub_out_5
number: 10
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light76"
pin:
pcf8574: pcf8574_hub_out_5
number: 11
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light77"
pin:
pcf8574: pcf8574_hub_out_5
number: 12
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light78"
pin:
pcf8574: pcf8574_hub_out_5
number: 13
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light79"
pin:
pcf8574: pcf8574_hub_out_5
number: 14
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light80"
pin:
pcf8574: pcf8574_hub_out_5
number: 15
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light81"
pin:
pcf8574: pcf8574_hub_out_6
number: 0
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light82"
pin:
pcf8574: pcf8574_hub_out_6
number: 1
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light83"
pin:
pcf8574: pcf8574_hub_out_6
number: 2
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light84"
pin:
pcf8574: pcf8574_hub_out_6
number: 3
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light85"
pin:
pcf8574: pcf8574_hub_out_6
number: 4
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light86"
pin:
pcf8574: pcf8574_hub_out_6
number: 5
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light87"
pin:
pcf8574: pcf8574_hub_out_6
number: 6
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light88"
pin:
pcf8574: pcf8574_hub_out_6
number: 7
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light89"
pin:
pcf8574: pcf8574_hub_out_6
number: 8
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light90"
pin:
pcf8574: pcf8574_hub_out_6
number: 9
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light91"
pin:
pcf8574: pcf8574_hub_out_6
number: 10
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light92"
pin:
pcf8574: pcf8574_hub_out_6
number: 11
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light93"
pin:
pcf8574: pcf8574_hub_out_6
number: 12
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light94"
pin:
pcf8574: pcf8574_hub_out_6
number: 13
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light95"
pin:
pcf8574: pcf8574_hub_out_6
number: 14
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light96"
pin:
pcf8574: pcf8574_hub_out_6
number: 15
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light97"
pin:
pcf8574: pcf8574_hub_out_7
number: 0
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light98"
pin:
pcf8574: pcf8574_hub_out_7
number: 1
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light99"
pin:
pcf8574: pcf8574_hub_out_7
number: 2
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light100"
pin:
pcf8574: pcf8574_hub_out_7
number: 3
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light101"
pin:
pcf8574: pcf8574_hub_out_7
number: 4
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light102"
pin:
pcf8574: pcf8574_hub_out_7
number: 5
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light103"
pin:
pcf8574: pcf8574_hub_out_7
number: 6
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light104"
pin:
pcf8574: pcf8574_hub_out_7
number: 7
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light105"
pin:
pcf8574: pcf8574_hub_out_7
number: 8
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light106"
pin:
pcf8574: pcf8574_hub_out_7
number: 9
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light107"
pin:
pcf8574: pcf8574_hub_out_7
number: 10
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light108"
pin:
pcf8574: pcf8574_hub_out_7
number: 11
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light109"
pin:
pcf8574: pcf8574_hub_out_7
number: 12
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light110"
pin:
pcf8574: pcf8574_hub_out_7
number: 13
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light111"
pin:
pcf8574: pcf8574_hub_out_7
number: 14
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light112"
pin:
pcf8574: pcf8574_hub_out_7
number: 15
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light113"
pin:
pcf8574: pcf8574_hub_out_8
number: 0
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light114"
pin:
pcf8574: pcf8574_hub_out_8
number: 1
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light115"
pin:
pcf8574: pcf8574_hub_out_8
number: 2
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light116"
pin:
pcf8574: pcf8574_hub_out_8
number: 3
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light117"
pin:
pcf8574: pcf8574_hub_out_8
number: 4
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light118"
pin:
pcf8574: pcf8574_hub_out_8
number: 5
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light119"
pin:
pcf8574: pcf8574_hub_out_8
number: 6
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light120"
pin:
pcf8574: pcf8574_hub_out_8
number: 7
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light121"
pin:
pcf8574: pcf8574_hub_out_8
number: 8
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light122"
pin:
pcf8574: pcf8574_hub_out_8
number: 9
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light123"
pin:
pcf8574: pcf8574_hub_out_8
number: 10
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light124"
pin:
pcf8574: pcf8574_hub_out_8
number: 11
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light125"
pin:
pcf8574: pcf8574_hub_out_8
number: 12
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light126"
pin:
pcf8574: pcf8574_hub_out_8
number: 13
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light127"
pin:
pcf8574: pcf8574_hub_out_8
number: 14
mode: OUTPUT
inverted: true

- platform: gpio
name: "a128-light128"
pin:
pcf8574: pcf8574_hub_out_8
number: 15
mode: OUTPUT
inverted: true

# Individual inputs
binary_sensor:
- platform: gpio
name: "a128-input1"
pin:
pcf8574: pcf8574_hub_in_1
number: 0
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input2"
pin:
pcf8574: pcf8574_hub_in_1
number: 1
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input3"
pin:
pcf8574: pcf8574_hub_in_1
number: 2
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input4"
pin:
pcf8574: pcf8574_hub_in_1
number: 3
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input5"
pin:
pcf8574: pcf8574_hub_in_1
number: 4
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input6"
pin:
pcf8574: pcf8574_hub_in_1
number: 5
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input7"
pin:
pcf8574: pcf8574_hub_in_1
number: 6
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input8"
pin:
pcf8574: pcf8574_hub_in_1
number: 7
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input9"
pin:
pcf8574: pcf8574_hub_in_1
number: 8
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input10"
pin:
pcf8574: pcf8574_hub_in_1
number: 9
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input11"
pin:
pcf8574: pcf8574_hub_in_1
number: 10
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input12"
pin:
pcf8574: pcf8574_hub_in_1
number: 11
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input13"
pin:
pcf8574: pcf8574_hub_in_1
number: 12
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input14"
pin:
pcf8574: pcf8574_hub_in_1
number: 13
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input15"
pin:
pcf8574: pcf8574_hub_in_1
number: 14
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input16"
pin:
pcf8574: pcf8574_hub_in_1
number: 15
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input17"
pin:
pcf8574: pcf8574_hub_in_2
number: 0
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input18"
pin:
pcf8574: pcf8574_hub_in_2
number: 1
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input19"
pin:
pcf8574: pcf8574_hub_in_2
number: 2
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input20"
pin:
pcf8574: pcf8574_hub_in_2
number: 3
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input21"
pin:
pcf8574: pcf8574_hub_in_2
number: 4
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input22"
pin:
pcf8574: pcf8574_hub_in_2
number: 5
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input23"
pin:
pcf8574: pcf8574_hub_in_2
number: 6
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input24"
pin:
pcf8574: pcf8574_hub_in_2
number: 7
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input25"
pin:
pcf8574: pcf8574_hub_in_2
number: 8
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input26"
pin:
pcf8574: pcf8574_hub_in_2
number: 9
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input27"
pin:
pcf8574: pcf8574_hub_in_2
number: 10
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input28"
pin:
pcf8574: pcf8574_hub_in_2
number: 11
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input29"
pin:
pcf8574: pcf8574_hub_in_2
number: 12
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input30"
pin:
pcf8574: pcf8574_hub_in_2
number: 13
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input31"
pin:
pcf8574: pcf8574_hub_in_2
number: 14
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input32"
pin:
pcf8574: pcf8574_hub_in_2
number: 15
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input33"
pin:
pcf8574: pcf8574_hub_in_3
number: 0
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input34"
pin:
pcf8574: pcf8574_hub_in_3
number: 1
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input35"
pin:
pcf8574: pcf8574_hub_in_3
number: 2
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input36"
pin:
pcf8574: pcf8574_hub_in_3
number: 3
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input37"
pin:
pcf8574: pcf8574_hub_in_3
number: 4
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input38"
pin:
pcf8574: pcf8574_hub_in_3
number: 5
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input39"
pin:
pcf8574: pcf8574_hub_in_3
number: 6
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input40"
pin:
pcf8574: pcf8574_hub_in_3
number: 7
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input41"
pin:
pcf8574: pcf8574_hub_in_3
number: 8
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input42"
pin:
pcf8574: pcf8574_hub_in_3
number: 9
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input43"
pin:
pcf8574: pcf8574_hub_in_3
number: 10
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input44"
pin:
pcf8574: pcf8574_hub_in_3
number: 11
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input45"
pin:
pcf8574: pcf8574_hub_in_3
number: 12
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input46"
pin:
pcf8574: pcf8574_hub_in_3
number: 13
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input47"
pin:
pcf8574: pcf8574_hub_in_3
number: 14
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input48"
pin:
pcf8574: pcf8574_hub_in_3
number: 15
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input49"
pin:
pcf8574: pcf8574_hub_in_4
number: 0
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input50"
pin:
pcf8574: pcf8574_hub_in_4
number: 1
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input51"
pin:
pcf8574: pcf8574_hub_in_4
number: 2
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input52"
pin:
pcf8574: pcf8574_hub_in_4
number: 3
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input53"
pin:
pcf8574: pcf8574_hub_in_4
number: 4
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input54"
pin:
pcf8574: pcf8574_hub_in_4
number: 5
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input55"
pin:
pcf8574: pcf8574_hub_in_4
number: 6
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input56"
pin:
pcf8574: pcf8574_hub_in_4
number: 7
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input57"
pin:
pcf8574: pcf8574_hub_in_4
number: 8
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input58"
pin:
pcf8574: pcf8574_hub_in_4
number: 9
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input59"
pin:
pcf8574: pcf8574_hub_in_4
number: 10
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input60"
pin:
pcf8574: pcf8574_hub_in_4
number: 11
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input61"
pin:
pcf8574: pcf8574_hub_in_4
number: 12
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input62"
pin:
pcf8574: pcf8574_hub_in_4
number: 13
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input63"
pin:
pcf8574: pcf8574_hub_in_4
number: 14
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input64"
pin:
pcf8574: pcf8574_hub_in_4
number: 15
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input65"
pin:
pcf8574: pcf8574_hub_in_5
number: 0
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input66"
pin:
pcf8574: pcf8574_hub_in_5
number: 1
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input67"
pin:
pcf8574: pcf8574_hub_in_5
number: 2
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input68"
pin:
pcf8574: pcf8574_hub_in_5
number: 3
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input69"
pin:
pcf8574: pcf8574_hub_in_5
number: 4
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input70"
pin:
pcf8574: pcf8574_hub_in_5
number: 5
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input71"
pin:
pcf8574: pcf8574_hub_in_5
number: 6
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input72"
pin:
pcf8574: pcf8574_hub_in_5
number: 7
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input73"
pin:
pcf8574: pcf8574_hub_in_5
number: 8
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input74"
pin:
pcf8574: pcf8574_hub_in_5
number: 9
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input75"
pin:
pcf8574: pcf8574_hub_in_5
number: 10
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input76"
pin:
pcf8574: pcf8574_hub_in_5
number: 11
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input77"
pin:
pcf8574: pcf8574_hub_in_5
number: 12
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input78"
pin:
pcf8574: pcf8574_hub_in_5
number: 13
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input79"
pin:
pcf8574: pcf8574_hub_in_5
number: 14
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input80"
pin:
pcf8574: pcf8574_hub_in_5
number: 15
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input81"
pin:
pcf8574: pcf8574_hub_in_6
number: 0
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input82"
pin:
pcf8574: pcf8574_hub_in_6
number: 1
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input83"
pin:
pcf8574: pcf8574_hub_in_6
number: 2
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input84"
pin:
pcf8574: pcf8574_hub_in_6
number: 3
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input85"
pin:
pcf8574: pcf8574_hub_in_6
number: 4
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input86"
pin:
pcf8574: pcf8574_hub_in_6
number: 5
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input87"
pin:
pcf8574: pcf8574_hub_in_6
number: 6
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input88"
pin:
pcf8574: pcf8574_hub_in_6
number: 7
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input89"
pin:
pcf8574: pcf8574_hub_in_6
number: 8
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input90"
pin:
pcf8574: pcf8574_hub_in_6
number: 9
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input91"
pin:
pcf8574: pcf8574_hub_in_6
number: 10
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input92"
pin:
pcf8574: pcf8574_hub_in_6
number: 11
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input93"
pin:
pcf8574: pcf8574_hub_in_6
number: 12
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input94"
pin:
pcf8574: pcf8574_hub_in_6
number: 13
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input95"
pin:
pcf8574: pcf8574_hub_in_6
number: 14
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input96"
pin:
pcf8574: pcf8574_hub_in_6
number: 15
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input97"
pin:
pcf8574: pcf8574_hub_in_7
number: 0
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input98"
pin:
pcf8574: pcf8574_hub_in_7
number: 1
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input99"
pin:
pcf8574: pcf8574_hub_in_7
number: 2
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input100"
pin:
pcf8574: pcf8574_hub_in_7
number: 3
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input101"
pin:
pcf8574: pcf8574_hub_in_7
number: 4
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input102"
pin:
pcf8574: pcf8574_hub_in_7
number: 5
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input103"
pin:
pcf8574: pcf8574_hub_in_7
number: 6
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input104"
pin:
pcf8574: pcf8574_hub_in_7
number: 7
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input105"
pin:
pcf8574: pcf8574_hub_in_7
number: 8
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input106"
pin:
pcf8574: pcf8574_hub_in_7
number: 9
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input107"
pin:
pcf8574: pcf8574_hub_in_7
number: 10
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input108"
pin:
pcf8574: pcf8574_hub_in_7
number: 11
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input109"
pin:
pcf8574: pcf8574_hub_in_7
number: 12
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input110"
pin:
pcf8574: pcf8574_hub_in_7
number: 13
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input111"
pin:
pcf8574: pcf8574_hub_in_7
number: 14
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input112"
pin:
pcf8574: pcf8574_hub_in_7
number: 15
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input113"
pin:
pcf8574: pcf8574_hub_in_8
number: 0
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input114"
pin:
pcf8574: pcf8574_hub_in_8
number: 1
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input115"
pin:
pcf8574: pcf8574_hub_in_8
number: 2
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input116"
pin:
pcf8574: pcf8574_hub_in_8
number: 3
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input117"
pin:
pcf8574: pcf8574_hub_in_8
number: 4
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input118"
pin:
pcf8574: pcf8574_hub_in_8
number: 5
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input119"
pin:
pcf8574: pcf8574_hub_in_8
number: 6
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input120"
pin:
pcf8574: pcf8574_hub_in_8
number: 7
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input121"
pin:
pcf8574: pcf8574_hub_in_8
number: 8
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input122"
pin:
pcf8574: pcf8574_hub_in_8
number: 9
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input123"
pin:
pcf8574: pcf8574_hub_in_8
number: 10
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input124"
pin:
pcf8574: pcf8574_hub_in_8
number: 11
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input125"
pin:
pcf8574: pcf8574_hub_in_8
number: 12
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input126"
pin:
pcf8574: pcf8574_hub_in_8
number: 13
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input127"
pin:
pcf8574: pcf8574_hub_in_8
number: 14
mode: INPUT
inverted: true

- platform: gpio
name: "a128-input128"
pin:
pcf8574: pcf8574_hub_in_8
number: 15
mode: INPUT
inverted: true

KC868-A128 ESP32 I/O pin define

Posted by: admin - 08-04-2022, 09:46 PM - Forum: KC868-A128 - No Replies

#define ANALOG_A1 GPIO39
#define ANALOG_A2 GPIO34
#define ANALOG_A3 GPIO36
#define ANALOG_A4 GPIO35

IIC Bus-1:A

SDA-A:GPIO5
SCL-A:GPIO16

PCF8575:U144 (relay1-16): 100 100 = 0x24
PCF8575:U146 (relay17-32): 100 101 = 0x25
PCF8575:U148 (relay33-48): 100 001 = 0x21
PCF8575:U150 (relay49-64): 100 010 = 0x22
PCF8575:U280 (relay65-80): 100 110 = 0x26
PCF8575:U282 (relay81-96): 100 111 = 0x27
PCF8575:U284 (relay97-112): 100 000 = 0x20
PCF8575:U286 (relay113-128): 100 011 = 0x23

IIC Bus-2:B
SDA-B:GPIO15
SCL-B:GPIO4

PCF8575:U143 (DI1-16): 100 100 = 0x24
PCF8575:U145 (DI17-32): 100 101 = 0x25
PCF8575:U147 (DI33-48): 100 001 = 0x21
PCF8575:U149 (DI49-64): 100 010 = 0x22
PCF8575:U279 (DI65-80): 100 110 = 0x26
PCF8575:U281 (DI81-96): 100 111 = 0x27
PCF8575:U283 (DI97-112): 100 000 = 0x20
PCF8575:U285 (DI113-128): 100 011 = 0x23

-----------------

Ethernet (LAN8720) I/O define:

#define ETH_ADDR 0
#define ETH_POWER_PIN -1
#define ETH_MDC_PIN 23
#define ETH_MDIO_PIN 18
#define ETH_TYPE ETH_PHY_LAN8720
#define ETH_CLK_MODE ETH_CLOCK_GPIO17_OUT

--------------------

RS485:
RXD:GPIO13
TXD:GPIO14

Extend serial port (3.3v TTL level):
RXD:GPIO32
TXD:GPIO33

Home Assistant Support

Posted by: naveenppm - 08-04-2022, 08:16 AM - Forum: DIY Project - Replies (2)

I am using TCP IN node for getting value. Depending on the value I need to set the value brightness of light 1 . my entity is input_number.light_1.

but I getting errors. how to write JSON for the above requirement.

Objective : Set the value to input_bumber.light_1 using json

please find the attachment for your reference..Please help me to sort out this issue.

Attached Files Thumbnail(s)

KC868-A128 ESP32 GPIO Module Released!

Posted by: admin - 08-04-2022, 02:45 AM - Forum: News - No Replies

We have designed KC868-A128 ESP32 board use for huge INPUT and OUTPUT devices for home automation DIY. it is a input module based on ESP32 chip. it have 128 channel digital input ports, every input channel use optocoupler isolation, so that can work for 1000 meter with sensors or any dry contact devices. Support work with RS485. Made For ESPHome and easily integrate to home assistant for smart home automation project DIY. You can write any code by Arduino IDE to ESP32 wifi/bluetooth/ethernet RS485 module.

[Image: KC868-A128-1_01.jpg]

[Image: KC868-A128-2_01.jpg]

KC868-A8 PCB updated V1.5

Posted by: admin - 08-04-2022, 01:34 AM - Forum: News - Replies (23)

	new pcb v1.5 of KC868-A8, replaced USB-C with MiniUSB port.

lesson33 - make a 3D dashboard for home assistant

Posted by: admin - 08-03-2022, 03:33 AM - Forum: Home automation training courses - Replies (4)

Here are our demo dashboard used frontend plugin in HACS:

Weather Card
Config Template Card
Simple Weather Card
Kiosk Mode
card-mod
mini-graph-card
button-card
Homekit panel card

Here is 3D dashboard demo video used config file:

.txt home-assistant-dashboard-3d-kincony-yaml.txt (Size: 35.28 KB / Downloads: 451)
Here is 3D dashboard sample photos:

.zip home-assistant-dashboard-3d-kincony.zip (Size: 4.87 MB / Downloads: 427)

KC868-A8 MQTT Can someone write me code for this

Posted by: pidetaanyhteytta - 08-02-2022, 06:26 PM - Forum: DIY Project - Replies (5)

Hi.
I need code for KC868-A8 V1.4 For MQTT Use just like in KC868-4 mqtt code what is is useles because i2C and it has only WIFI.

Ineed
1. LAN Configuration with static ip and dhcp disabled with //
2.WIFI Configuration with static ip but not in use //
3.MQTT control lines i will edit subs and bups. inputs has to buplish and outputs has to subscribe
4. example how to make output control momentary or latching.
Can somebody help me . i have tried but i need code to learn and cant find eny clear code to read and understand.

KC868-A16 Tasmota and RS485

Posted by: alex_neo - 07-29-2022, 06:25 AM - Forum: DIY Project - Replies (3)

Please tell me (if it possible) how to use rs 485 port with tasmota firmware?
I've got some rs 485 devices (such as C02 sensors, wind speed and so on) and want them to receive data from. Like i receive data from tasmota sensors to my mqtt server by json strings.

I have connected to rs 485 port some of them (powered on of cource) but no data came. like nothing happens.

Is it really possible with KC868-A16 or I must search some other device?

Thank you.

Pages (254): « Previous 1 … 177 178 179 180 181 182 183 184 185 186 187 188 189 190 191 192 193 194 195 196 197 … 254 Next »

Login
Username:
Password:	Lost Password?
	Remember me
